Quick Specs
  • Designed For Aggressive Trail ⚡
  • F. Travel 160 MM
  • R. Travel 150 MM
  • Wheel Size 27.5 Wide Trail

Ride more, further, faster. The Altitude Powerplay brings cutting-edge power to an aggressive trail bike, and opens the door to amazing terrain for all.

Introducing a fully integrated, electric-assist mountain bike that takes our Altitude’s legendary handling and ride quality and adds a compact, powerful drive system. The new Powerplay™ drive system was designed in parallel with the frame, delivering ultra-short chainstays, optimised suspension kinematics, super-low centre of gravity, and class-leading torque. The result is an e-MTB that actually rides like a proper mountain bike—perfect for everything from self-shuttling all mountain trails, finding flow between the descents, and squeezing in power lunch rides.

It’s an Altitude

The Altitude Powerplay has the same geometry and suspension performance as the unassisted Altitude platform. It is the first e-MTB that features true aggressive trail ride feel.

Next generation drive system

The Powerplay™ drive system was designed from the ground up to allow true mountain bike performance, while providing class-leading torque, massive battery capacity, and ultra quiet operation.

Intuitive pedal assist

An in-line torque sensor provides smooth, instant power response, making for an intuitive, natural ride with no learning curve. Get on and go.

Charge fast, then charge hard

The 48v motor provides super short charge times, taking only two hours to reach 80% capacity of the available 632Wh lithium ion battery.

Fully supported

Easily serviceable components, with both replacement parts and strong dealer service support in Europe.

Made in Canada
Altitude Powerplay Carbon 50 3
Colour Colour
Colour Colour Colour
Colour Colour

Specifications: Altitude Powerplay Carbon 50

    • Frame SMOOTHWALL™ carbon front triangle, FORM™ alloy rear triangle. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. ISCG05 Tabs. RIDE-9™ Adjustable Geometry + Suspension Rate. 250 W / 48V Powerplay Drive. Li-Ion 632 Watt/Hr.
    • Sizes S - M - L - XL
    • Fork Fox 36 Float EVOL Grip Performance 160mm
    • Front Travel 160mm
    • Shock Fox Float DPS EVOL Performance Elite
    • Rear Travel 150mm
    • Headset FSA Orbit NO.57 Steerer Stop
    • Stem Rocky Mountain 35 AM
    • Handlebar Race Face Chester 780mm
    • Grips Rocky Mountain Lock On Light
    • Brakes Sram Guide RE. Sram Centerline 200mm.
    • Brake Levers Sram Guide RE
    • Shifters Sram EX1
    • Rear Derailleur Sram EX1
    • Cranks & Chainrings Race Face Turbine Cinch 34T
    • Bottom Bracket Race Face BB92
    • Cassette Sram XG-899 11-48T
    • Chain Sram EX1
    • Front Hub Rocky Mountain Sealed Boost 15mm
    • Rear Hub DT Swiss 350 Boost 148mm
    • Spokes WTB 2.0-1.8
    • Rims Sun Düroc 40. Tubeless Ready - Tape / Valves Incl.
    • Tires Maxxis Minion DHF WT EXO Tubeless Ready 27.5 x 2.5
    • Seatpost Fox Transfer Performance Elite 30.9mm. S: 125mm Drop / M - XL: 150mm Drop.
    • Saddle WTB Silverado Race
    • Weight 49.2lb (22.3kg)
    • Frame SMOOTHWALL™ carbon frame. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. ISCG05 Tabs. RIDE-9™ Adjustable Geometry + Suspension Rate. 250 W / 48V Powerplay Drive. Li-Ion 632 Watt/Hr.
    • Sizes S - M - L - XL
    • Fork Fox 36 Float EVOL FIT4 Factory 160mm
    • Front Travel 160mm
    • Shock Fox Float DPS EVOL Factory
    • Rear Travel 150mm
    • Headset FSA Orbit NO.57 Steerer Stop
    • Stem Rocky Mountain 35 CNC DH
    • Handlebar Race Face Next R 780mm
    • Grips Rocky Mountain Lock On XC
    • Brakes Sram Guide RE. Sram Centerline 200mm.
    • Brake Levers Sram Guide RE
    • Shifters Sram EX1
    • Rear Derailleur Sram EX1
    • Cranks & Chainrings Race Face Next Cinch 34T
    • Bottom Bracket Race Face BB92
    • Cassette Sram XG-899 11-48T
    • Chain Sram EX1
    • Front Hub Rocky Mountain Sealed Boost 15mm
    • Rear Hub DT Swiss 350 Boost 148mm
    • Spokes WTB 2.0-1.8
    • Rims Rocky Mountain 30AM Carbon. Tubeless Ready - Tape / Valves Incl.
    • Tires Maxxis Minion DHF WT Maxx Terra 3C Tubeless Ready 27.5 x 2.5
    • Seatpost Fox Transfer Performance Elite 30.9mm. S: 125mm Drop / M - XL: 150mm Drop.
    • Saddle WTB Silverado Race
    • Weight 47.6lb (21.6kg)
    • Frame SMOOTHWALL™ Carbon. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. ISCG05 Tabs. RIDE-9™ Adjustable Geometry + Suspension Rate. 250 W / 48V Powerplay Drive. Li-Ion 500 Watt/Hr.
    • Sizes S - M - L - XL
    • Fork RockShox Yari RC 160mm
    • Front Travel 160mm
    • Shock RockShox Deluxe RT
    • Rear Travel 150mm
    • Headset FSA Orbit NO.57 Steerer Stop
    • Stem Rocky Mountain 35 AM
    • Handlebar Race Face Chester 780mm
    • Grips Rocky Mountain Lock On Light
    • Brakes Sram Guide RE. Sram Centerline 200mm.
    • Brake Levers Sram Guide RE
    • Shifters Sram EX1
    • Rear Derailleur Sram EX1
    • Cranks & Chainrings Race Face Turbine Cinch 34T
    • Bottom Bracket Race Face BB92
    • Cassette Sram XG-899 11-48T
    • Chain Sram EX1
    • Front Hub Rocky Mountain Sealed Boost 15mm
    • Rear Hub Sram MTH 746 Boost 148mm
    • Spokes WTB 2.0
    • Rims Sun Düroc 40. Tubeless Ready - Tape / Valves Incl.
    • Tires Maxxis Minion DHF WT EXO Tubeless Ready 27.5 x 2.5
    • Seatpost Race Face Aeffect Dropper 30.9mm. S: 125mm Drop / M - XL: 150mm Drop.
    • Saddle WTB Volt Race
    • Weight 49.1lb (22.3kg)

We make every effort to ensure accuracy, but reserve the right to update specifications & prices without notification

Geometry: Altitude Powerplay Carbon 50

Riding Style

Measured with standard 2.5" Wide Trail tires and a 160mm 27.5 fork.

Measured using a 10mm taller lower headset cup, a standard 160mm 27.5 fork, and 26x3.0 tires.

Measured with standard 2.5" Wide Trail tires and a 160mm 27.5 fork.

Measured using a 10mm taller lower headset cup, a standard 160mm 27.5 fork, and 26x3.0 tires.

Measured with standard 2.5" Wide Trail tires and a 160mm 27.5 fork.

Measured using a 10mm taller lower headset cup, a standard 160mm 27.5 fork, and 26x3.0 tires.

s m l xl
TTH Top Tube Length - HORZ 578 578mm 603 603mm 628 628mm 658 658mm
HTA Head Tube Angle 64.5 64.5deg 65 65deg 65 65deg 65 65deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74 74deg 74 74deg 74 74deg 74 74deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 13 13mm 13 13mm 13 13mm 13 13mm
R Reach 407 407mm 430 430mm 452 452mm 479 479mm
S Stack 583 583mm 604 604mm 613 613mm 628 628mm
SH Standover Height 810 810mm 814 814mm 814 814mm 814 814mm
WB Wheelbase 1157 1157mm 1180 1180mm 1206 1206mm 1239 1239mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 628 628mm 658 658mm
HTA Head Tube Angle 64.7 64.7deg 65.1 65.1deg 65.1 65.1deg 65.1 65.1deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.1 74.1deg 74.1 74.1deg 74.1 74.1deg 74.1 74.1deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 12 12mm 12 12mm 12 12mm 12 12mm
R Reach 409 409mm 431 431mm 454 454mm 481 481mm
S Stack 582 582mm 603 603mm 613 613mm 626 626mm
SH Standover Height 811 811mm 815 815mm 815 815mm 815 815mm
WB Wheelbase 1157 1157mm 1179 1179mm 1206 1206mm 1239 1239mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 64.8 64.8deg 65.3 65.3deg 65.3 65.3deg 65.3 65.3deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 10 10mm 10 10mm 10 10mm 10 10mm
R Reach 411 411mm 434 434mm 456 456mm 483 483mm
S Stack 581 581mm 602 602mm 611 611mm 625 625mm
SH Standover Height 812 812mm 816 816mm 816 816mm 816 816mm
WB Wheelbase 1157 1157mm 1179 1179mm 1206 1206mm 1238 1238mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 64.9 64.9deg 65.4 65.4deg 65.4 65.4deg 65.4 65.4deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.4 74.4deg 74.4 74.4deg 74.4 74.4deg 74.4 74.4deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 425 425mm 425 425mm 425 425mm 425 425mm
BBD Bottom bracket drop 10 10mm 10 10mm 10 10mm 10 10mm
R Reach 410 410mm 433 433mm 456 456mm 482 482mm
S Stack 580 580mm 602 602mm 611 611mm 625 625mm
SH Standover Height 812 812mm 817 817mm 817 817mm 817 817mm
WB Wheelbase 1156 1156mm 1179 1179mm 1206 1206mm 1238 1238mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 65 65deg 65.6 65.6deg 65.6 65.6deg 65.6 65.6deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.6 74.6deg 74.6 74.6deg 74.6 74.6deg 74.6 74.6deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 425 425mm 425 425mm 425 425mm 425 425mm
BBD Bottom bracket drop 7 7mm 7 7mm 7 7mm 7 7mm
R Reach 413 413mm 435 435mm 458 458mm 484 484mm
S Stack 579 579mm 600 600mm 610 610mm 623 623mm
SH Standover Height 813 813mm 817 817mm 817 817mm 817 817mm
WB Wheelbase 1156 1156mm 1179 1179mm 1205 1205mm 1238 1238mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 65.2 65.2deg 65.7 65.7deg 65.7 65.7deg 65.7 65.7deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 424 424mm 424 424mm 424 424mm 424 424mm
BBD Bottom bracket drop 4 4mm 4 4mm 4 4mm 4 4mm
R Reach 415 415mm 438 438mm 460 460mm 487 487mm
S Stack 578 578mm 599 599mm 608 608mm 622 622mm
SH Standover Height 814 814mm 818 818mm 818 818mm 818 818mm
WB Wheelbase 1156 1156mm 1178 1178mm 1205 1205mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 65.3 65.3deg 65.8 65.8deg 65.8 65.8deg 65.8 65.8deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.8 74.8deg 74.8 74.8deg 74.8 74.8deg 74.8 74.8deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 424 424mm 424 424mm 424 424mm 424 424mm
BBD Bottom bracket drop 4 4mm 4 4mm 4 4mm 4 4mm
R Reach 415 415mm 437 437mm 460 460mm 486 486mm
S Stack 577 577mm 599 599mm 608 608mm 622 622mm
SH Standover Height 814 814mm 818 818mm 818 818mm 818 818mm
WB Wheelbase 1156 1156mm 1178 1178mm 1205 1205mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 575 575mm 600 600mm 625 625mm 655 655mm
HTA Head Tube Angle 65.4 65.4deg 65.9 65.9deg 65.9 65.9deg 65.9 65.9deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.9 74.9deg 74.9 74.9deg 74.9 74.9deg 74.9 74.9deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 424 424mm 424 424mm 424 424mm 424 424mm
BBD Bottom bracket drop 2 2mm 2 2mm 2 2mm 2 2mm
R Reach 417 417mm 439 439mm 462 462mm 488 488mm
S Stack 576 576mm 597 597mm 607 607mm 620 620mm
SH Standover Height 815 815mm 819 819mm 819 819mm 819 819mm
WB Wheelbase 1155 1155mm 1178 1178mm 1204 1204mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 575 575mm 600 600mm 625 625mm 655 655mm
HTA Head Tube Angle 65.6 65.6deg 66.1 66.1deg 66.1 66.1deg 66.1 66.1deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 75.1 75.1deg 75.1 75.1deg 75.1 75.1deg 75.1 75.1deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop -1 -1mm -1 -1mm -1 -1mm -1 -1mm
R Reach 419 419mm 441 441mm 464 464mm 490 490mm
S Stack 575 575mm 596 596mm 605 605mm 619 619mm
SH Standover Height 816 816mm 820 820mm 820 820mm 820 820mm
WB Wheelbase 1155 1155mm 1177 1177mm 1204 1204mm 1236 1236mm
s m l xl
TTH Top Tube Length - HORZ 579 579mm 604 604mm 629 629mm 659 659mm
HTA Head Tube Angle 64.1 64.1deg 64.6 64.6deg 64.6 64.6deg 64.6 64.6deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 73.6 73.6deg 73.6 73.6deg 73.6 73.6deg 73.6 73.6deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 11 11mm 11 11mm 11 11mm 11 11mm
R Reach 403 403mm 425 425mm 448 448mm 474 474mm
S Stack 586 586mm 608 608mm 617 617mm 631 631mm
SH Standover Height 810 810mm 813 813mm 813 813mm 813 813mm
WB Wheelbase 1162 1162mm 1184 1184mm 1211 1211mm 1243 1243mm
s m l xl
TTH Top Tube Length - HORZ 579 579mm 604 604mm 629 629mm 659 659mm
HTA Head Tube Angle 64.3 64.3deg 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 73.8 73.8deg 73.8 73.8deg 73.8 73.8deg 73.8 73.8deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 9 9mm 9 9mm 9 9mm 9 9mm
R Reach 404 404mm 427 427mm 449 449mm 476 476mm
S Stack 585 585mm 607 607mm 616 616mm 630 630mm
SH Standover Height 811 811mm 813 813mm 813 813mm 813 813mm
WB Wheelbase 1161 1161mm 1184 1184mm 1210 1210mm 1243 1243mm
s m l xl
TTH Top Tube Length - HORZ 578 578mm 603 603mm 628 628mm 658 658mm
HTA Head Tube Angle 64.4 64.4deg 65 65deg 65 65deg 65 65deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74 74deg 74 74deg 74 74deg 74 74deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 425 425mm 425 425mm 425 425mm 425 425mm
BBD Bottom bracket drop 6 6mm 6 6mm 6 6mm 6 6mm
R Reach 407 407mm 429 429mm 452 452mm 478 478mm
S Stack 584 584mm 605 605mm 614 614mm 628 628mm
SH Standover Height 812 812mm 814 814mm 814 814mm 814 814mm
WB Wheelbase 1161 1161mm 1183 1183mm 1210 1210mm 1242 1242mm
s m l xl
TTH Top Tube Length - HORZ 578 578mm 603 603mm 628 628mm 658 658mm
HTA Head Tube Angle 64.5 64.5deg 64.9 64.9deg 64.9 64.9deg 64.9 64.9deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 73.9 73.9deg 73.9 73.9deg 73.9 73.9deg 73.9 73.9deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 7 7mm 7 7mm 7 7mm 7 7mm
R Reach 406 406mm 428 428mm 451 451mm 477 477mm
S Stack 583 583mm 605 605mm 615 615mm 629 629mm
SH Standover Height 812 812mm 814 814mm 814 814mm 814 814mm
WB Wheelbase 1161 1161mm 1183 1183mm 1210 1210mm 1242 1242mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 64.6 64.6deg 65.1 65.1deg 65.1 65.1deg 65.1 65.1deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.1 74.1deg 74.1 74.1deg 74.1 74.1deg 74.1 74.1deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 425 425mm 425 425mm 425 425mm 425 425mm
BBD Bottom bracket drop 4 4mm 4 4mm 4 4mm 4 4mm
R Reach 408 408mm 431 431mm 453 453mm 480 480mm
S Stack 582 582mm 604 604mm 613 613mm 627 627mm
SH Standover Height 813 813mm 816 816mm 816 816mm 816 816mm
WB Wheelbase 1161 1161mm 1183 1183mm 1209 1209mm 1242 1242mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 64.7 64.7deg 65.3 65.3deg 65.3 65.3deg 65.3 65.3deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 424 424mm 424 424mm 424 424mm 424 424mm
BBD Bottom bracket drop 1 1mm 1 1mm 1 1mm 1 1mm
R Reach 410 410mm 433 433mm 456 456mm 482 482mm
S Stack 581 581mm 602 602mm 611 611mm 625 625mm
SH Standover Height 814 814mm 817 817mm 817 817mm 817 817mm
WB Wheelbase 1160 1160mm 1182 1182mm 1209 1209mm 1240 1240mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 64.9 64.9deg 65.3 65.3deg 65.3 65.3deg 65.3 65.3deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 425 425mm 425 425mm 425 425mm 425 425mm
BBD Bottom bracket drop 1 1mm 1 1mm 1 1mm 1 1mm
R Reach 410 410mm 433 433mm 455 455mm 482 482mm
S Stack 580 580mm 602 602mm 612 612mm 626 626mm
SH Standover Height 814 814mm 816 816mm 816 816mm 816 816mm
WB Wheelbase 1160 1160mm 1182 1182mm 1209 1209mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 65 65deg 65.5 65.5deg 65.5 65.5deg 65.5 65.5deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.5 74.5deg 74.5 74.5deg 74.5 74.5deg 74.5 74.5deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 424 424mm 424 424mm 424 424mm 424 424mm
BBD Bottom bracket drop 1 1mm 1 1mm 1 1mm 1 1mm
R Reach 412 412mm 435 435mm 457 457mm 484 484mm
S Stack 579 579mm 601 601mm 610 610mm 624 624mm
SH Standover Height 815 815mm 818 818mm 818 818mm 818 818mm
WB Wheelbase 1159 1159mm 1182 1182mm 1208 1208mm 1271 1271mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 65.2 65.2deg 65.7 65.7deg 65.7 65.7deg 65.7 65.7deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 423 423mm 423 423mm 423 423mm 423 423mm
BBD Bottom bracket drop -4 -4mm -4 -4mm -4 -4mm -4 -4mm
R Reach 414 414mm 437 437mm 459 459mm 486 486mm
S Stack 578 578mm 599 599mm 609 609mm 622 622mm
SH Standover Height 816 816mm 819 819mm 819 819mm 819 819mm
WB Wheelbase 1159 1159mm 1181 1181mm 1208 1208mm 1240 1240mm
s m l xl
TTH Top Tube Length - HORZ 578 578mm 603 603mm 628 628mm 658 658mm
HTA Head Tube Angle 64.5 64.5deg 65 65deg 65 65deg 65 65deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74 74deg 74 74deg 74 74deg 74 74deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 13 13mm 13 13mm 13 13mm 13 13mm
R Reach 407 407mm 430 430mm 452 452mm 479 479mm
S Stack 583 583mm 604 604mm 613 613mm 628 628mm
SH Standover Height 810 810mm 814 814mm 814 814mm 814 814mm
WB Wheelbase 1157 1157mm 1180 1180mm 1206 1206mm 1239 1239mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 628 628mm 658 658mm
HTA Head Tube Angle 64.7 64.7deg 65.1 65.1deg 65.1 65.1deg 65.1 65.1deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.1 74.1deg 74.1 74.1deg 74.1 74.1deg 74.1 74.1deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 12 12mm 12 12mm 12 12mm 12 12mm
R Reach 409 409mm 431 431mm 454 454mm 481 481mm
S Stack 582 582mm 603 603mm 613 613mm 626 626mm
SH Standover Height 811 811mm 815 815mm 815 815mm 815 815mm
WB Wheelbase 1157 1157mm 1179 1179mm 1206 1206mm 1239 1239mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 64.8 64.8deg 65.3 65.3deg 65.3 65.3deg 65.3 65.3deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 10 10mm 10 10mm 10 10mm 10 10mm
R Reach 411 411mm 434 434mm 456 456mm 483 483mm
S Stack 581 581mm 602 602mm 611 611mm 625 625mm
SH Standover Height 812 812mm 816 816mm 816 816mm 816 816mm
WB Wheelbase 1157 1157mm 1179 1179mm 1206 1206mm 1238 1238mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 64.9 64.9deg 65.4 65.4deg 65.4 65.4deg 65.4 65.4deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.4 74.4deg 74.4 74.4deg 74.4 74.4deg 74.4 74.4deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 425 425mm 425 425mm 425 425mm 425 425mm
BBD Bottom bracket drop 10 10mm 10 10mm 10 10mm 10 10mm
R Reach 410 410mm 433 433mm 456 456mm 482 482mm
S Stack 580 580mm 602 602mm 611 611mm 625 625mm
SH Standover Height 812 812mm 817 817mm 817 817mm 817 817mm
WB Wheelbase 1156 1156mm 1179 1179mm 1206 1206mm 1238 1238mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 65 65deg 65.6 65.6deg 65.6 65.6deg 65.6 65.6deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.6 74.6deg 74.6 74.6deg 74.6 74.6deg 74.6 74.6deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 425 425mm 425 425mm 425 425mm 425 425mm
BBD Bottom bracket drop 7 7mm 7 7mm 7 7mm 7 7mm
R Reach 413 413mm 435 435mm 458 458mm 484 484mm
S Stack 579 579mm 600 600mm 610 610mm 623 623mm
SH Standover Height 813 813mm 817 817mm 817 817mm 817 817mm
WB Wheelbase 1156 1156mm 1179 1179mm 1205 1205mm 1238 1238mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 65.2 65.2deg 65.7 65.7deg 65.7 65.7deg 65.7 65.7deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 424 424mm 424 424mm 424 424mm 424 424mm
BBD Bottom bracket drop 4 4mm 4 4mm 4 4mm 4 4mm
R Reach 415 415mm 438 438mm 460 460mm 487 487mm
S Stack 578 578mm 599 599mm 608 608mm 622 622mm
SH Standover Height 814 814mm 818 818mm 818 818mm 818 818mm
WB Wheelbase 1156 1156mm 1178 1178mm 1205 1205mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 65.3 65.3deg 65.8 65.8deg 65.8 65.8deg 65.8 65.8deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.8 74.8deg 74.8 74.8deg 74.8 74.8deg 74.8 74.8deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 424 424mm 424 424mm 424 424mm 424 424mm
BBD Bottom bracket drop 4 4mm 4 4mm 4 4mm 4 4mm
R Reach 415 415mm 437 437mm 460 460mm 486 486mm
S Stack 577 577mm 599 599mm 608 608mm 622 622mm
SH Standover Height 814 814mm 818 818mm 818 818mm 818 818mm
WB Wheelbase 1156 1156mm 1178 1178mm 1205 1205mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 575 575mm 600 600mm 625 625mm 655 655mm
HTA Head Tube Angle 65.4 65.4deg 65.9 65.9deg 65.9 65.9deg 65.9 65.9deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.9 74.9deg 74.9 74.9deg 74.9 74.9deg 74.9 74.9deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 424 424mm 424 424mm 424 424mm 424 424mm
BBD Bottom bracket drop 2 2mm 2 2mm 2 2mm 2 2mm
R Reach 417 417mm 439 439mm 462 462mm 488 488mm
S Stack 576 576mm 597 597mm 607 607mm 620 620mm
SH Standover Height 815 815mm 819 819mm 819 819mm 819 819mm
WB Wheelbase 1155 1155mm 1178 1178mm 1204 1204mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 575 575mm 600 600mm 625 625mm 655 655mm
HTA Head Tube Angle 65.6 65.6deg 66.1 66.1deg 66.1 66.1deg 66.1 66.1deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 75.1 75.1deg 75.1 75.1deg 75.1 75.1deg 75.1 75.1deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop -1 -1mm -1 -1mm -1 -1mm -1 -1mm
R Reach 419 419mm 441 441mm 464 464mm 490 490mm
S Stack 575 575mm 596 596mm 605 605mm 619 619mm
SH Standover Height 816 816mm 820 820mm 820 820mm 820 820mm
WB Wheelbase 1155 1155mm 1177 1177mm 1204 1204mm 1236 1236mm
s m l xl
TTH Top Tube Length - HORZ 579 579mm 604 604mm 629 629mm 659 659mm
HTA Head Tube Angle 64.1 64.1deg 64.6 64.6deg 64.6 64.6deg 64.6 64.6deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 73.6 73.6deg 73.6 73.6deg 73.6 73.6deg 73.6 73.6deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 11 11mm 11 11mm 11 11mm 11 11mm
R Reach 403 403mm 425 425mm 448 448mm 474 474mm
S Stack 586 586mm 608 608mm 617 617mm 631 631mm
SH Standover Height 810 810mm 813 813mm 813 813mm 813 813mm
WB Wheelbase 1162 1162mm 1184 1184mm 1211 1211mm 1243 1243mm
s m l xl
TTH Top Tube Length - HORZ 579 579mm 604 604mm 629 629mm 659 659mm
HTA Head Tube Angle 64.3 64.3deg 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 73.8 73.8deg 73.8 73.8deg 73.8 73.8deg 73.8 73.8deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 9 9mm 9 9mm 9 9mm 9 9mm
R Reach 404 404mm 427 427mm 449 449mm 476 476mm
S Stack 585 585mm 607 607mm 616 616mm 630 630mm
SH Standover Height 811 811mm 813 813mm 813 813mm 813 813mm
WB Wheelbase 1161 1161mm 1184 1184mm 1210 1210mm 1243 1243mm
s m l xl
TTH Top Tube Length - HORZ 578 578mm 603 603mm 628 628mm 658 658mm
HTA Head Tube Angle 64.4 64.4deg 65 65deg 65 65deg 65 65deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74 74deg 74 74deg 74 74deg 74 74deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 425 425mm 425 425mm 425 425mm 425 425mm
BBD Bottom bracket drop 6 6mm 6 6mm 6 6mm 6 6mm
R Reach 407 407mm 429 429mm 452 452mm 478 478mm
S Stack 584 584mm 605 605mm 614 614mm 628 628mm
SH Standover Height 812 812mm 814 814mm 814 814mm 814 814mm
WB Wheelbase 1161 1161mm 1183 1183mm 1210 1210mm 1242 1242mm
s m l xl
TTH Top Tube Length - HORZ 578 578mm 603 603mm 628 628mm 658 658mm
HTA Head Tube Angle 64.5 64.5deg 64.9 64.9deg 64.9 64.9deg 64.9 64.9deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 73.9 73.9deg 73.9 73.9deg 73.9 73.9deg 73.9 73.9deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 7 7mm 7 7mm 7 7mm 7 7mm
R Reach 406 406mm 428 428mm 451 451mm 477 477mm
S Stack 583 583mm 605 605mm 615 615mm 629 629mm
SH Standover Height 812 812mm 814 814mm 814 814mm 814 814mm
WB Wheelbase 1161 1161mm 1183 1183mm 1210 1210mm 1242 1242mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 64.6 64.6deg 65.1 65.1deg 65.1 65.1deg 65.1 65.1deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.1 74.1deg 74.1 74.1deg 74.1 74.1deg 74.1 74.1deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 425 425mm 425 425mm 425 425mm 425 425mm
BBD Bottom bracket drop 4 4mm 4 4mm 4 4mm 4 4mm
R Reach 408 408mm 431 431mm 453 453mm 480 480mm
S Stack 582 582mm 604 604mm 613 613mm 627 627mm
SH Standover Height 813 813mm 816 816mm 816 816mm 816 816mm
WB Wheelbase 1161 1161mm 1183 1183mm 1209 1209mm 1242 1242mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 64.7 64.7deg 65.3 65.3deg 65.3 65.3deg 65.3 65.3deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 424 424mm 424 424mm 424 424mm 424 424mm
BBD Bottom bracket drop 1 1mm 1 1mm 1 1mm 1 1mm
R Reach 410 410mm 433 433mm 456 456mm 482 482mm
S Stack 581 581mm 602 602mm 611 611mm 625 625mm
SH Standover Height 814 814mm 817 817mm 817 817mm 817 817mm
WB Wheelbase 1160 1160mm 1182 1182mm 1209 1209mm 1240 1240mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 64.9 64.9deg 65.3 65.3deg 65.3 65.3deg 65.3 65.3deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 425 425mm 425 425mm 425 425mm 425 425mm
BBD Bottom bracket drop 1 1mm 1 1mm 1 1mm 1 1mm
R Reach 410 410mm 433 433mm 455 455mm 482 482mm
S Stack 580 580mm 602 602mm 612 612mm 626 626mm
SH Standover Height 814 814mm 816 816mm 816 816mm 816 816mm
WB Wheelbase 1160 1160mm 1182 1182mm 1209 1209mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 65 65deg 65.5 65.5deg 65.5 65.5deg 65.5 65.5deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.5 74.5deg 74.5 74.5deg 74.5 74.5deg 74.5 74.5deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 424 424mm 424 424mm 424 424mm 424 424mm
BBD Bottom bracket drop 1 1mm 1 1mm 1 1mm 1 1mm
R Reach 412 412mm 435 435mm 457 457mm 484 484mm
S Stack 579 579mm 601 601mm 610 610mm 624 624mm
SH Standover Height 815 815mm 818 818mm 818 818mm 818 818mm
WB Wheelbase 1159 1159mm 1182 1182mm 1208 1208mm 1271 1271mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 65.2 65.2deg 65.7 65.7deg 65.7 65.7deg 65.7 65.7deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 423 423mm 423 423mm 423 423mm 423 423mm
BBD Bottom bracket drop -4 -4mm -4 -4mm -4 -4mm -4 -4mm
R Reach 414 414mm 437 437mm 459 459mm 486 486mm
S Stack 578 578mm 599 599mm 609 609mm 622 622mm
SH Standover Height 816 816mm 819 819mm 819 819mm 819 819mm
WB Wheelbase 1159 1159mm 1181 1181mm 1208 1208mm 1240 1240mm
s m l xl
TTH Top Tube Length - HORZ 578 578mm 603 603mm 628 628mm 658 658mm
HTA Head Tube Angle 64.5 64.5deg 65 65deg 65 65deg 65 65deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74 74deg 74 74deg 74 74deg 74 74deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 13 13mm 13 13mm 13 13mm 13 13mm
R Reach 407 407mm 430 430mm 452 452mm 479 479mm
S Stack 583 583mm 604 604mm 613 613mm 628 628mm
SH Standover Height 810 810mm 814 814mm 814 814mm 814 814mm
WB Wheelbase 1157 1157mm 1180 1180mm 1206 1206mm 1239 1239mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 628 628mm 658 658mm
HTA Head Tube Angle 64.7 64.7deg 65.1 65.1deg 65.1 65.1deg 65.1 65.1deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.1 74.1deg 74.1 74.1deg 74.1 74.1deg 74.1 74.1deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 12 12mm 12 12mm 12 12mm 12 12mm
R Reach 409 409mm 431 431mm 454 454mm 481 481mm
S Stack 582 582mm 603 603mm 613 613mm 626 626mm
SH Standover Height 811 811mm 815 815mm 815 815mm 815 815mm
WB Wheelbase 1157 1157mm 1179 1179mm 1206 1206mm 1239 1239mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 64.8 64.8deg 65.3 65.3deg 65.3 65.3deg 65.3 65.3deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 426 426mm 426 426mm 426 426mm 426 426mm
BBD Bottom bracket drop 10 10mm 10 10mm 10 10mm 10 10mm
R Reach 411 411mm 434 434mm 456 456mm 483 483mm
S Stack 581 581mm 602 602mm 611 611mm 625 625mm
SH Standover Height 812 812mm 816 816mm 816 816mm 816 816mm
WB Wheelbase 1157 1157mm 1179 1179mm 1206 1206mm 1238 1238mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 64.9 64.9deg 65.4 65.4deg 65.4 65.4deg 65.4 65.4deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.4 74.4deg 74.4 74.4deg 74.4 74.4deg 74.4 74.4deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 425 425mm 425 425mm 425 425mm 425 425mm
BBD Bottom bracket drop 10 10mm 10 10mm 10 10mm 10 10mm
R Reach 410 410mm 433 433mm 456 456mm 482 482mm
S Stack 580 580mm 602 602mm 611 611mm 625 625mm
SH Standover Height 812 812mm 817 817mm 817 817mm 817 817mm
WB Wheelbase 1156 1156mm 1179 1179mm 1206 1206mm 1238 1238mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 65 65deg 65.6 65.6deg 65.6 65.6deg 65.6 65.6deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.6 74.6deg 74.6 74.6deg 74.6 74.6deg 74.6 74.6deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 425 425mm 425 425mm 425 425mm 425 425mm
BBD Bottom bracket drop 7 7mm 7 7mm 7 7mm 7 7mm
R Reach 413 413mm 435 435mm 458 458mm 484 484mm
S Stack 579 579mm 600 600mm 610 610mm 623 623mm
SH Standover Height 813 813mm 817 817mm 817 817mm 817 817mm
WB Wheelbase 1156 1156mm 1179 1179mm 1205 1205mm 1238 1238mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 65.2 65.2deg 65.7 65.7deg 65.7 65.7deg 65.7 65.7deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 424 424mm 424 424mm 424 424mm 424 424mm
BBD Bottom bracket drop 4 4mm 4 4mm 4 4mm 4 4mm
R Reach 415 415mm 438 438mm 460 460mm 487 487mm
S Stack 578 578mm 599 599mm 608 608mm 622 622mm
SH Standover Height 814 814mm 818 818mm 818 818mm 818 818mm
WB Wheelbase 1156 1156mm 1178 1178mm 1205 1205mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 65.3 65.3deg 65.8 65.8deg 65.8 65.8deg 65.8 65.8deg
HTL Head Tube length 110 110mm 120 120mm 130 130mm 145 145mm
STA Seat Tube Angle - Effective 74.8 74.8deg 74.8 74.8deg 74.8 74.8deg 74.8 74.8deg
STL Seat Tube length 419 419mm 457 457mm 482.5 482.5mm 520.5 520.5mm
RC Rear Centre 424 424mm 424 424mm 424 424mm 424 424mm
BBD Bottom bracket drop 4 4mm 4 4mm 4 4mm 4 4mm
R Reach 415 415mm 437 437mm
