Instinct

Instinct

Quick Specs
  • Designed For Trail
  • F. Travel 140 (160 BC Ed) MM
  • R. Travel 140 (155 BC Ed) MM
  • Wheel Size 29" (27.5+ ready)

Stable and aggressive, the Instinct is our most versatile trail bike.

With 29" wheels and a wide range of RIDE-9™ adjustments, the all new Instinct is available in both carbon and alloy models. An all-new frame for 2018 pushes the rear travel to 140mm, increasing stiffness and tweaking the suspension kinematics. Despite the increase in travel, the new frame has noticeably more efficient pedaling, with better small-bump sensitivity and a host of next-generation features.

---

The Instinct BC Edition is our all-new Instinct platform, built up as an even more aggressive trail monster.

Designed with an optimized single-position link, ultra-aggressive geometry, and a long stroke shock that provides 155mm of rear travel, we’ve kitted out the Instinct BC with wide bars, big tires, ultra-stiff wheels, and more capable suspension. It smashes all mountain lines, rails corners, and plows over everything in sight, while displaying all the climbing efficiency that makes the Instinct a crowd favourite.

Instinct Alloy 50 7
MSRP $2,799 USD
MSRP $5, 899 USD
MSRP $3,199 USD
MSRP $4,199 USD
MSRP $3,649 USD
MSRP $4,299 USD
MSRP $5,299 USD
MSRP $2,799 USD
MSRP $5, 899 USD
MSRP $5,299 USD
MSRP $4,299 USD
MSRP $3,649 USD
MSRP $4,199 USD
MSRP $3,199 USD
Colour Colour Colour
Colour Colour Colour
Colour Colour
Colour Colour Colour
Colour Colour Colour
Colour Colour Colour
Colour Colour Colour

Specifications: Instinct Alloy 50

    • Sizes S - M - L - XL
    • Frame SMOOTHWALL™ Carbon. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing.
    • Fork Fox 36 Float EVOL FIT4 Performance Elite 160mm
    • Front Travel 160 mm
    • Shock Fox Float DPX2 Performance Elite
    • Rear Travel 155 mm
    • Headset FSA Orbit NO.57E Extend-o-matic
    • Stem Rocky Mountain 35 CNC DH
    • Handlebar Race Face Turbine R 780mm
    • Grips Rocky Mountain Lock On XC
    • Brakes Sram Code R
    • Shifters Sram GX Eagle
    • Front Derailleur Rocky Mountain Spirit Guide
    • Rear Derailleur Sram GX Eagle
    • Cranks & Chainrings Sram Stylo 7k Eagle 32T
    • Bottom Bracket Sram GXP BB92
    • Cassette Sram XG-1275 10-50T
    • Chain Sram GX Eagle
    • Front Hub Rocky Mountain Sealed Boost 15mm
    • Rear Hub DT Swiss 370 Boost 148mm
    • Spokes WTB 1.8-1.6
    • Rims Stans Flow MK3 Tubeless Ready - Tape / Valves Incl
    • Tires Maxxis 29 DHF 2.5 EXO Maxx Terra 3C TR / Maxxis 29 DHRII 2.4 WT EXO Maxx Terra 3C TR
    • Seatpost Fox Transfer Performance Elite 30.9mm
    • Saddle WTB Silverado Race
    • Sizes S - M - L - XL
    • Frame SMOOTHWALL™ Carbon. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing.
    • Front Travel Max 160 mm
    • Shock Fox Float DPX2 Factory
    • Rear Travel 155 mm
    • Front Derailleur Rocky Mountain Spirit Guide
    • Sizes S - M - L - XL
    • Frame SMOOTHWALL™ Carbon. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. RIDE-9™ Adjustable Geometry + Suspension Rate
    • Fork Fox 34 Float Performance Elite 140mm
    • Front Travel 140 mm
    • Shock Fox Float DPS EVOL Performance Elite
    • Rear Travel 140 mm
    • Headset FSA Orbit NO.57E Extend-o-matic
    • Stem Rocky Mountain 35 AM
    • Handlebar Race Face Turbine R 780mm
    • Grips Rocky Mountain Lock On XC
    • Brakes Sram Guide R
    • Shifters Sram GX Eagle
    • Front Derailleur Rocky Mountain Spirit Guide
    • Rear Derailleur Sram GX Eagle
    • Cranks & Chainrings Sram Stylo 7k Eagle 32T
    • Bottom Bracket Sram GXP BB92
    • Cassette Sram XG-1275 10-50T
    • Chain Sram GX Eagle
    • Front Hub Rocky Mountain Sealed Boost 15mm
    • Rear Hub DT Swiss 370 Boost 148mm
    • Spokes WTB 1.8-1.6
    • Rims Stans Arch MK3 Tubeless Ready - Tape / Valves Incl
    • Tires Maxxis Minion DHR II EXO Tubeless Ready 29 x 2.3 / Maxxis Forekaster EXO Tubeless Ready 29 x 2.35
    • Seatpost Fox Transfer Performance Elite 30.9mm
    • Saddle WTB Silverado Race
    • Sizes S - M - L - XL
    • Frame SMOOTHWALL™ Carbon. FORM™ Alloy Rear Triangle. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. RIDE-9™ Adjustable Geometry + Suspension Rate
    • Fork Fox 34 Float Performance 140mm
    • Front Travel 140 mm
    • Shock Fox Float DPS EVOL Performance
    • Rear Travel 140 mm
    • Headset FSA Orbit NO.57E Extend-o-matic
    • Stem Rocky Mountain AM
    • Handlebar Rocky Mountain AM 760mm
    • Grips Rocky Mountain Lock On Light
    • Brakes Sram Level TL
    • Shifters Sram GX Eagle
    • Front Derailleur Rocky Mountain Spirit Guide
    • Rear Derailleur Sram GX Eagle
    • Cranks & Chainrings Sram Stylo 6k Eagle 32T
    • Bottom Bracket Sram GXP BB92
    • Cassette Sram XG-1275 10-50T
    • Chain Sram GX Eagle
    • Front Hub Rocky Mountain Sealed Boost 15mm
    • Rear Hub DT Swiss 370 Boost 148mm
    • Spokes WTB 2.0-1.8
    • Rims Sun Düroc 30 Tubeless Compatible - Tape / Valves / Sealant Not Incl
    • Tires Maxxis Minion DHR II EXO Tubeless Ready 29 x 2.3 / Maxxis Forekaster EXO Tubeless Ready 29 x 2.35
    • Seatpost Race Face Aeffect Dropper 30.9mm
    • Saddle WTB Volt Race
    • Sizes S - M - L - XL
    • Frame SMOOTHWALL™ Carbon. FORM™ Alloy Rear Triangle. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. RIDE-9™ Adjustable Geometry + Suspension Rate
    • Fork RockShox Reba RL 140mm
    • Front Travel 140 mm
    • Shock RockShox Deluxe Debonair RT
    • Rear Travel 140 mm
    • Headset FSA Orbit NO.57E Extend-o-matic
    • Stem Rocky Mountain AM
    • Handlebar Rocky Mountain AM 760mm
    • Grips Rocky Mountain Lock On Light
    • Brakes Sram Level
    • Shifters Sram NX
    • Front Derailleur Rocky Mountain Spirit Guide
    • Rear Derailleur Sram NX
    • Cranks & Chainrings Race Face Aeffect Cinch 30T Steel
    • Bottom Bracket Race Face BB92
    • Cassette Sram PG-1130 11-42T
    • Chain Sram PC-1110
    • Front Hub Rocky Mountain Sealed Boost 15mm
    • Rear Hub Sram MTH 746 Boost 148mm
    • Spokes WTB 2.0
    • Rims Sun Helix TR27 SL Tubeless Compatible - Tape / Valves / Sealant Not Incl
    • Tires Maxxis Minion DHR II EXO Tubeless Ready 29 x 2.3 / Maxxis Forekaster EXO Tubeless Ready 29 x 2.35
    • Seatpost Race Face Aeffect Dropper 30.9mm
    • Saddle WTB Volt
    • Sizes S - M - L - XL
    • Frame FORM™ Alloy. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. ISCG05 Tabs. RIDE-9™ Adjustable Geometry + Suspension Rate
    • Fork Fox 34 Float Performance Elite 140mm
    • Front Travel 140 mm
    • Shock Fox Float DPS EVOL Performance Elite
    • Rear Travel 140 mm
    • Headset FSA Orbit NO.57E Extend-o-matic
    • Stem Rocky Mountain 35 AM
    • Handlebar Race Face Turbine R 780mm
    • Grips Rocky Mountain Lock On XC
    • Brakes Sram Guide R
    • Shifters Sram GX Eagle
    • Front Derailleur Rocky Mountain Spirit Guide
    • Rear Derailleur Sram GX Eagle
    • Cranks & Chainrings Sram Stylo 7k Eagle 32T
    • Bottom Bracket Sram GXP BB92
    • Cassette Sram XG-1275 10-50T
    • Chain Sram GX Eagle
    • Front Hub Rocky Mountain Sealed Boost 15mm
    • Rear Hub Sram MTH 746 Boost 148mm
    • Spokes WTB 1.8-1.6
    • Rims Sun Düroc 30 Tubeless Ready - Tape / Valves Incl
    • Tires Maxxis Minion DHR II EXO Tubeless Ready 29 x 2.3 / Maxxis Forekaster EXO Tubeless Ready 29 x 2.35
    • Seatpost Fox Transfer Performance Elite 30.9mm
    • Saddle WTB Silverado Race
    • Sizes S - M - L - XL
    • Frame FORM™ Alloy. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. ISCG05 Tabs. RIDE-9™ Adjustable Geometry + Suspension Rate
    • Fork Fox 34 Float Performance 140mm
    • Front Travel 140 mm
    • Shock Fox Float DPS EVOL Performance
    • Rear Travel 140 mm
    • Headset FSA Orbit NO.57E Extend-o-matic
    • Stem Rocky Mountain AM
    • Handlebar Rocky Mountain AM 760mm
    • Grips Rocky Mountain Lock On Light
    • Brakes Sram Level T
    • Shifters Sram GX
    • Front Derailleur Rocky Mountain Spirit Guide
    • Rear Derailleur Sram GX
    • Cranks & Chainrings Race Face Aeffect Cinch 30T Steel
    • Bottom Bracket Race Face BB92
    • Cassette Sram PG-1130 11-42T
    • Chain Sram PC-1110
    • Front Hub Rocky Mountain Sealed Boost 15mm
    • Rear Hub Sram MTH 746 Boost 148mm
    • Spokes WTB 2.0-1.8
    • Rims Sun Düroc 30 Tubeless Compatible - Tape / Valves / Sealant Not Incl
    • Tires Maxxis Minion DHR II EXO Tubeless Ready 29 x 2.3 / Maxxis Forekaster EXO Tubeless Ready 29 x 2.35
    • Seatpost Race Face Aeffect Dropper 30.9mm
    • Saddle WTB Volt Race

We make every effort to ensure accuracy, but reserve the right to update specifications & prices without notification

Geometry: Instinct Alloy 50

Riding Style

s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 65.9 65.9deg 65.9 65.9deg 65.9 65.9deg 65.9 65.9deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.4 74.4deg 74.4 74.4deg 74.4 74.4deg 74.4 74.4deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 19 19mm 19 19mm 19 19mm 19 19mm
R Reach 407 407mm 431 431mm 454 454mm 481 481mm
S Stack 607 607mm 612 612mm 621 621mm 630 630mm
SH Standover Height 828 828mm 828 828mm 828 828mm 828 828mm
WB Wheelbase 1161 1161mm 1187 1187mm 1213 1213mm 1245 1245mm
s m l xl
TTH Top Tube Length - HORZ 578 578mm 603 603mm 628 628mm 658 658mm
HTA Head Tube Angle 65.5 65.5deg 65.5 65.5deg 65.5 65.5deg 65.5 65.5deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74 74deg 74 74deg 74 74deg 74 74deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 16 16mm 16 16mm 16 16mm 16 16mm
R Reach 403 403mm 426 426mm 449 449mm 477 477mm
S Stack 610 610mm 615 615mm 625 625mm 634 634mm
SH Standover Height 824 824mm 824 824mm 824 824mm 824 824mm
WB Wheelbase 1165 1165mm 1191 1191mm 1217 1217mm 1249 1249mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 65.9 65.9deg 65.9 65.9deg 65.9 65.9deg 65.9 65.9deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.4 74.4deg 74.4 74.4deg 74.4 74.4deg 74.4 74.4deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 19 19mm 19 19mm 19 19mm 19 19mm
R Reach 407 407mm 431 431mm 454 454mm 481 481mm
S Stack 607 607mm 612 612mm 621 621mm 630 630mm
SH Standover Height 828 828mm 828 828mm 828 828mm 828 828mm
WB Wheelbase 1161 1161mm 1187 1187mm 1213 1213mm 1245 1245mm
s m l xl
TTH Top Tube Length - HORZ 578 578mm 603 603mm 628 628mm 658 658mm
HTA Head Tube Angle 65.5 65.5deg 65.5 65.5deg 65.5 65.5deg 65.5 65.5deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74 74deg 74 74deg 74 74deg 74 74deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 16 16mm 16 16mm 16 16mm 16 16mm
R Reach 403 403mm 426 426mm 449 449mm 477 477mm
S Stack 610 610mm 615 615mm 625 625mm 634 634mm
SH Standover Height 824 824mm 824 824mm 824 824mm 824 824mm
WB Wheelbase 1165 1165mm 1191 1191mm 1217 1217mm 1249 1249mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 66 66deg 66 66deg 66 66deg 66 66deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.5 74.5deg 74.5 74.5deg 74.5 74.5deg 74.5 74.5deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 436 436mm 436 436mm 436 436mm 436 436mm
BBD Bottom bracket drop 36 36mm 36 36mm 37 37mm 37 37mm
R Reach 408 408mm 432 432mm 455 455mm 482 482mm
S Stack 607 607mm 611 611mm 621 621mm 630 630mm
SH Standover Height 810 810mm 810 810mm 810 810mm 810 810mm
WB Wheelbase 1154 1154mm 1179 1179mm 1206 1206mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 66.1 66.1deg 66.1 66.1deg 66.1 66.1deg 66.1 66.1deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.6 74.6deg 74.6 74.6deg 74.6 74.6deg 74.6 74.6deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 436 436mm 436 436mm 436 436mm 436 436mm
BBD Bottom bracket drop 35 35mm 35 35mm 35 35mm 35 35mm
R Reach 409 409mm 433 433mm 456 456mm 483 483mm
S Stack 606 606mm 610 610mm 620 620mm 629 629mm
SH Standover Height 811 811mm 811 811mm 811 811mm 811 811mm
WB Wheelbase 1154 1154mm 1179 1179mm 1206 1206mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 66.2 66.2deg 66.2 66.2deg 66.2 66.2deg 66.2 66.2deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 33 33mm 34 34mm 34 34mm 34 34mm
R Reach 411 411mm 434 434mm 457 457mm 484 484mm
S Stack 605 605mm 610 610mm 619 619mm 628 628mm
SH Standover Height 811 811mm 811 811mm 811 811mm 811 811mm
WB Wheelbase 1153 1153mm 1179 1179mm 1206 1206mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 575 575mm 600 600mm 625 625mm 655 655mm
HTA Head Tube Angle 66.4 66.4deg 66.4 66.4deg 66.4 66.4deg 66.4 66.4deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.9 74.9deg 74.9 74.9deg 74.9 74.9deg 74.9 74.9deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 32 32mm 32 32mm 32 32mm 32 32mm
R Reach 412 412mm 436 436mm 458 458mm 486 486mm
S Stack 604 604mm 608 608mm 618 618mm 627 627mm
SH Standover Height 812 812mm 812 812mm 812 812mm 812 812mm
WB Wheelbase 1153 1153mm 1179 1179mm 1206 1206mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 575 575mm 600 600mm 625 625mm 655 655mm
HTA Head Tube Angle 66.5 66.5deg 66.5 66.5deg 66.5 66.5deg 66.5 66.5deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 75 75deg 75 75deg 75 75deg 75 75deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 30 30mm 30 30mm 30 30mm 30 30mm
R Reach 413 413mm 437 437mm 460 460mm 487 487mm
S Stack 603 603mm 608 608mm 617 617mm 626 626mm
SH Standover Height 813 813mm 813 813mm 813 813mm 813 813mm
WB Wheelbase 1153 1153mm 1179 1179mm 1205 1205mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 575 575mm 600 600mm 625 625mm 655 655mm
HTA Head Tube Angle 66.6 66.6deg 66.6 66.6deg 66.6 66.6deg 66.6 66.6deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 75.1 75.1deg 75.1 75.1deg 75.1 75.1deg 75.1 75.1deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 28 28mm 28 28mm 28 28mm 28 28mm
R Reach 415 415mm 439 439mm 461 461mm 489 489mm
S Stack 602 602mm 607 607mm 616 616mm 625 625mm
SH Standover Height 813 813mm 813 813mm 813 813mm 813 813mm
WB Wheelbase 1153 1153mm 1179 1179mm 1205 1205mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 574 574mm 599 599mm 624 624mm 654 654mm
HTA Head Tube Angle 66.7 66.7deg 66.7 66.7deg 66.7 66.7deg 66.7 66.7deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 75.2 75.2deg 75.2 75.2deg 75.2 75.2deg 75.2 75.2deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 27 27mm 27 27mm 27 27mm 27 27mm
R Reach 416 416mm 440 440mm 462 462mm 490 490mm
S Stack 601 601mm 606 606mm 615 615mm 624 624mm
SH Standover Height 814 814mm 814 814mm 814 814mm 814 814mm
WB Wheelbase 1153 1153mm 1179 1179mm 1205 1205mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 574 574mm 599 599mm 624 624mm 654 654mm
HTA Head Tube Angle 66.9 66.9deg 66.9 66.9deg 66.9 66.9deg 66.9 66.9deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 75.4 75.4deg 75.4 75.4deg 75.4 75.4deg 75.4 75.4deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 434 434mm 434 434mm 434 434mm 434 434mm
BBD Bottom bracket drop 25 25mm 25 25mm 25 25mm 25 25mm
R Reach 417 417mm 441 441mm 464 464mm 491 491mm
S Stack 600 600mm 605 605mm 614 614mm 623 623mm
SH Standover Height 815 815mm 815 815mm 815 815mm 815 815mm
WB Wheelbase 1153 1153mm 1178 1178mm 1205 1205mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 574 574mm 599 599mm 624 624mm 654 654mm
HTA Head Tube Angle 67 67deg 67 67deg 67 67deg 67 67deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 75.5 75.5deg 75.5 75.5deg 75.5 75.5deg 75.5 75.5deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 434 434mm 434 434mm 434 434mm 434 434mm
BBD Bottom bracket drop 23 23mm 23 23mm 23 23mm 23 23mm
R Reach 419 419mm 443 443mm 465 465mm 493 493mm
S Stack 599 599mm 604 604mm 613 613mm 622 622mm
SH Standover Height 815 815mm 815 815mm 815 815mm 815 815mm
WB Wheelbase 1153 1153mm 1178 1178mm 1205 1205mm 1236 1236mm
s m l xl
TTH Top Tube Length - HORZ 578 578mm 603 603mm 628 628mm 658 658mm
HTA Head Tube Angle 65.5 65.5deg 65.6 65.6deg 65.6 65.6deg 65.6 65.6deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74 74deg 74.1 74.1deg 74.1 74.1deg 74.1 74.1deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 436 436mm 436 436mm 436 436mm 436 436mm
BBD Bottom bracket drop 33 33mm 33 33mm 33 33mm 33 33mm
R Reach 403 403mm 427 427mm 450 450mm 477 477mm
S Stack 610 610mm 615 615mm 624 624mm 633 633mm
SH Standover Height 806 806mm 806 806mm 806 806mm 806 806mm
WB Wheelbase 1158 1158mm 1183 1183mm 1210 1210mm 1242 1242mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 65.7 65.7deg 65.7 65.7deg 65.7 65.7deg 65.7 65.7deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.2 74.2deg 74.2 74.2deg 74.2 74.2deg 74.2 74.2deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 436 436mm 436 436mm 436 436mm 436 436mm
BBD Bottom bracket drop 31 31mm 32 32mm 32 32mm 32 32mm
R Reach 405 405mm 428 428mm 451 451mm 479 479mm
S Stack 609 609mm 614 614mm 623 623mm 633 633mm
SH Standover Height 807 807mm 807 807mm 807 807mm 807 807mm
WB Wheelbase 1158 1158mm 1183 1183mm 1210 1210mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 65.8 65.8deg 65.8 65.8deg 65.8 65.8deg 65.8 65.8deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 436 436mm 436 436mm 436 436mm 436 436mm
BBD Bottom bracket drop 30 30mm 30 30mm 30 30mm 30 30mm
R Reach 406 406mm 430 430mm 452 452mm 480 480mm
S Stack 608 608mm 613 613mm 622 622mm 632 632mm
SH Standover Height 807 807mm 807 807mm 807 807mm 807 807mm
WB Wheelbase 1158 1158mm 1183 1183mm 1210 1210mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 65.9 65.9deg 65.9 65.9deg 65.9 65.9deg 66 66deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.4 74.4deg 74.4 74.4deg 74.4 74.4deg 74.5 74.5deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 28 28mm 28 28mm 28 28mm 28 28mm
R Reach 407 407mm 431 431mm 454 454mm 481 481mm
S Stack 607 607mm 612 612mm 621 621mm 630 630mm
SH Standover Height 808 808mm 808 808mm 808 808mm 808 808mm
WB Wheelbase 1157 1157mm 1183 1183mm 1210 1210mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 66 66deg 66.1 66.1deg 66.1 66.1deg 66.1 66.1deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.5 74.5deg 74.6 74.6deg 74.6 74.6deg 74.6 74.6deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 27 27mm 27 27mm 27 27mm 27 27mm
R Reach 409 409mm 432 432mm 455 455mm 483 483mm
S Stack 606 606mm 611 611mm 620 620mm 629 629mm
SH Standover Height 809 809mm 809 809mm 809 809mm 809 809mm
WB Wheelbase 1157 1157mm 1183 1183mm 1209 1209mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 66.2 66.2deg 66.2 66.2deg 66.2 66.2deg 66.2 66.2deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 25 25mm 25 25mm 25 25mm 25 25mm
R Reach 410 410mm 434 434mm 456 456mm 484 484mm
S Stack 605 605mm 610 610mm 619 619mm 628 628mm
SH Standover Height 809 809mm 809 809mm 809 809mm 809 809mm
WB Wheelbase 1157 1157mm 1183 1183mm 1209 1209mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 66.3 66.3deg 66.3 66.3deg 66.3 66.3deg 66.3 66.3deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.8 74.8deg 74.8 74.8deg 74.8 74.8deg 74.8 74.8deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 23 23mm 24 24mm 24 24mm 24 24mm
R Reach 411 411mm 435 435mm 458 458mm 485 485mm
S Stack 604 604mm 609 609mm 618 618mm 628 628mm
SH Standover Height 810 810mm 810 810mm 810 810mm 810 810mm
WB Wheelbase 1157 1157mm 1183 1183mm 1209 1209mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 575 575mm 600 600mm 625 625mm 655 655mm
HTA Head Tube Angle 66.4 66.4deg 66.4 66.4deg 66.4 66.4deg 66.4 66.4deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.9 74.9deg 74.9 74.9deg 74.9 74.9deg 74.9 74.9deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 22 22mm 22 22mm 22 22mm 22 22mm
R Reach 413 413mm 436 436mm 459 459mm 487 487mm
S Stack 603 603mm 608 608mm 617 617mm 626 626mm
SH Standover Height 811 811mm 811 811mm 811 811mm 811 811mm
WB Wheelbase 1157 1157mm 1182 1182mm 1209 1209mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 575 575mm 600 600mm 625 625mm 655 655mm
HTA Head Tube Angle 66.6 66.6deg 66.6 66.6deg 66.6 66.6deg 66.6 66.6deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 75.1 75.1deg 75.1 75.1deg 75.1 75.1deg 75.1 75.1deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 434 434mm 434 434mm 434 434mm 434 434mm
BBD Bottom bracket drop 20 20mm 20 20mm 20 20mm 20 20mm
R Reach 414 414mm 438 438mm 461 461mm 488 488mm
S Stack 602 602mm 607 607mm 616 616mm 625 625mm
SH Standover Height 811 811mm 811 811mm 811 811mm 811 811mm
WB Wheelbase 1157 1157mm 1182 1182mm 1209 1209mm 1240 1240mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 66 66deg 66 66deg 66 66deg 66 66deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.5 74.5deg 74.5 74.5deg 74.5 74.5deg 74.5 74.5deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 436 436mm 436 436mm 436 436mm 436 436mm
BBD Bottom bracket drop 36 36mm 36 36mm 37 37mm 37 37mm
R Reach 408 408mm 432 432mm 455 455mm 482 482mm
S Stack 607 607mm 611 611mm 621 621mm 630 630mm
SH Standover Height 810 810mm 810 810mm 810 810mm 810 810mm
WB Wheelbase 1154 1154mm 1179 1179mm 1206 1206mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 66.1 66.1deg 66.1 66.1deg 66.1 66.1deg 66.1 66.1deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.6 74.6deg 74.6 74.6deg 74.6 74.6deg 74.6 74.6deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 436 436mm 436 436mm 436 436mm 436 436mm
BBD Bottom bracket drop 35 35mm 35 35mm 35 35mm 35 35mm
R Reach 409 409mm 433 433mm 456 456mm 483 483mm
S Stack 606 606mm 610 610mm 620 620mm 629 629mm
SH Standover Height 811 811mm 811 811mm 811 811mm 811 811mm
WB Wheelbase 1154 1154mm 1179 1179mm 1206 1206mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 66.2 66.2deg 66.2 66.2deg 66.2 66.2deg 66.2 66.2deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 33 33mm 34 34mm 34 34mm 34 34mm
R Reach 411 411mm 434 434mm 457 457mm 484 484mm
S Stack 605 605mm 610 610mm 619 619mm 628 628mm
SH Standover Height 811 811mm 811 811mm 811 811mm 811 811mm
WB Wheelbase 1153 1153mm 1179 1179mm 1206 1206mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 575 575mm 600 600mm 625 625mm 655 655mm
HTA Head Tube Angle 66.4 66.4deg 66.4 66.4deg 66.4 66.4deg 66.4 66.4deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.9 74.9deg 74.9 74.9deg 74.9 74.9deg 74.9 74.9deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 32 32mm 32 32mm 32 32mm 32 32mm
R Reach 412 412mm 436 436mm 458 458mm 486 486mm
S Stack 604 604mm 608 608mm 618 618mm 627 627mm
SH Standover Height 812 812mm 812 812mm 812 812mm 812 812mm
WB Wheelbase 1153 1153mm 1179 1179mm 1206 1206mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 575 575mm 600 600mm 625 625mm 655 655mm
HTA Head Tube Angle 66.5 66.5deg 66.5 66.5deg 66.5 66.5deg 66.5 66.5deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 75 75deg 75 75deg 75 75deg 75 75deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 30 30mm 30 30mm 30 30mm 30 30mm
R Reach 413 413mm 437 437mm 460 460mm 487 487mm
S Stack 603 603mm 608 608mm 617 617mm 626 626mm
SH Standover Height 813 813mm 813 813mm 813 813mm 813 813mm
WB Wheelbase 1153 1153mm 1179 1179mm 1205 1205mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 575 575mm 600 600mm 625 625mm 655 655mm
HTA Head Tube Angle 66.6 66.6deg 66.6 66.6deg 66.6 66.6deg 66.6 66.6deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 75.1 75.1deg 75.1 75.1deg 75.1 75.1deg 75.1 75.1deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 28 28mm 28 28mm 28 28mm 28 28mm
R Reach 415 415mm 439 439mm 461 461mm 489 489mm
S Stack 602 602mm 607 607mm 616 616mm 625 625mm
SH Standover Height 813 813mm 813 813mm 813 813mm 813 813mm
WB Wheelbase 1153 1153mm 1179 1179mm 1205 1205mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 574 574mm 599 599mm 624 624mm 654 654mm
HTA Head Tube Angle 66.7 66.7deg 66.7 66.7deg 66.7 66.7deg 66.7 66.7deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 75.2 75.2deg 75.2 75.2deg 75.2 75.2deg 75.2 75.2deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 27 27mm 27 27mm 27 27mm 27 27mm
R Reach 416 416mm 440 440mm 462 462mm 490 490mm
S Stack 601 601mm 606 606mm 615 615mm 624 624mm
SH Standover Height 814 814mm 814 814mm 814 814mm 814 814mm
WB Wheelbase 1153 1153mm 1179 1179mm 1205 1205mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 574 574mm 599 599mm 624 624mm 654 654mm
HTA Head Tube Angle 66.9 66.9deg 66.9 66.9deg 66.9 66.9deg 66.9 66.9deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 75.4 75.4deg 75.4 75.4deg 75.4 75.4deg 75.4 75.4deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 434 434mm 434 434mm 434 434mm 434 434mm
BBD Bottom bracket drop 25 25mm 25 25mm 25 25mm 25 25mm
R Reach 417 417mm 441 441mm 464 464mm 491 491mm
S Stack 600 600mm 605 605mm 614 614mm 623 623mm
SH Standover Height 815 815mm 815 815mm 815 815mm 815 815mm
WB Wheelbase 1153 1153mm 1178 1178mm 1205 1205mm 1237 1237mm
s m l xl
TTH Top Tube Length - HORZ 574 574mm 599 599mm 624 624mm 654 654mm
HTA Head Tube Angle 67 67deg 67 67deg 67 67deg 67 67deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 75.5 75.5deg 75.5 75.5deg 75.5 75.5deg 75.5 75.5deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 434 434mm 434 434mm 434 434mm 434 434mm
BBD Bottom bracket drop 23 23mm 23 23mm 23 23mm 23 23mm
R Reach 419 419mm 443 443mm 465 465mm 493 493mm
S Stack 599 599mm 604 604mm 613 613mm 622 622mm
SH Standover Height 815 815mm 815 815mm 815 815mm 815 815mm
WB Wheelbase 1153 1153mm 1178 1178mm 1205 1205mm 1236 1236mm
s m l xl
TTH Top Tube Length - HORZ 578 578mm 603 603mm 628 628mm 658 658mm
HTA Head Tube Angle 65.5 65.5deg 65.6 65.6deg 65.6 65.6deg 65.6 65.6deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74 74deg 74.1 74.1deg 74.1 74.1deg 74.1 74.1deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 436 436mm 436 436mm 436 436mm 436 436mm
BBD Bottom bracket drop 33 33mm 33 33mm 33 33mm 33 33mm
R Reach 403 403mm 427 427mm 450 450mm 477 477mm
S Stack 610 610mm 615 615mm 624 624mm 633 633mm
SH Standover Height 806 806mm 806 806mm 806 806mm 806 806mm
WB Wheelbase 1158 1158mm 1183 1183mm 1210 1210mm 1242 1242mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 65.7 65.7deg 65.7 65.7deg 65.7 65.7deg 65.7 65.7deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.2 74.2deg 74.2 74.2deg 74.2 74.2deg 74.2 74.2deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 436 436mm 436 436mm 436 436mm 436 436mm
BBD Bottom bracket drop 31 31mm 32 32mm 32 32mm 32 32mm
R Reach 405 405mm 428 428mm 451 451mm 479 479mm
S Stack 609 609mm 614 614mm 623 623mm 633 633mm
SH Standover Height 807 807mm 807 807mm 807 807mm 807 807mm
WB Wheelbase 1158 1158mm 1183 1183mm 1210 1210mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 65.8 65.8deg 65.8 65.8deg 65.8 65.8deg 65.8 65.8deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg 74.3 74.3deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 436 436mm 436 436mm 436 436mm 436 436mm
BBD Bottom bracket drop 30 30mm 30 30mm 30 30mm 30 30mm
R Reach 406 406mm 430 430mm 452 452mm 480 480mm
S Stack 608 608mm 613 613mm 622 622mm 632 632mm
SH Standover Height 807 807mm 807 807mm 807 807mm 807 807mm
WB Wheelbase 1158 1158mm 1183 1183mm 1210 1210mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 577 577mm 602 602mm 627 627mm 657 657mm
HTA Head Tube Angle 65.9 65.9deg 65.9 65.9deg 65.9 65.9deg 66 66deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.4 74.4deg 74.4 74.4deg 74.4 74.4deg 74.5 74.5deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 28 28mm 28 28mm 28 28mm 28 28mm
R Reach 407 407mm 431 431mm 454 454mm 481 481mm
S Stack 607 607mm 612 612mm 621 621mm 630 630mm
SH Standover Height 808 808mm 808 808mm 808 808mm 808 808mm
WB Wheelbase 1157 1157mm 1183 1183mm 1210 1210mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 66 66deg 66.1 66.1deg 66.1 66.1deg 66.1 66.1deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.5 74.5deg 74.6 74.6deg 74.6 74.6deg 74.6 74.6deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 27 27mm 27 27mm 27 27mm 27 27mm
R Reach 409 409mm 432 432mm 455 455mm 483 483mm
S Stack 606 606mm 611 611mm 620 620mm 629 629mm
SH Standover Height 809 809mm 809 809mm 809 809mm 809 809mm
WB Wheelbase 1157 1157mm 1183 1183mm 1209 1209mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 66.2 66.2deg 66.2 66.2deg 66.2 66.2deg 66.2 66.2deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg 74.7 74.7deg
STL Seat Tube length 392 392mm 432 432mm 470 470mm 508 508mm
RC Rear Centre 435 435mm 435 435mm 435 435mm 435 435mm
BBD Bottom bracket drop 25 25mm 25 25mm 25 25mm 25 25mm
R Reach 410 410mm 434 434mm 456 456mm 484 484mm
S Stack 605 605mm 610 610mm 619 619mm 628 628mm
SH Standover Height 809 809mm 809 809mm 809 809mm 809 809mm
WB Wheelbase 1157 1157mm 1183 1183mm 1209 1209mm 1241 1241mm
s m l xl
TTH Top Tube Length - HORZ 576 576mm 601 601mm 626 626mm 656 656mm
HTA Head Tube Angle 66.3 66.3deg 66.3 66.3deg 66.3 66.3deg 66.3 66.3deg
HTL Head Tube length 95 95mm 100 100mm 110 110mm 120 120mm
STA Seat Tube Angle - Effective 74.8 74.8deg 74.8 74.8deg 74.8 74.8deg 74.8 74.8deg
STL Seat Tube length 392
