Thunderbolt

Lightning fast, the Thunderbolt is our vision of a perfect XC-trail bike.

Thunderbolt

Travel: 130mm (F) / 120mm (R)

Wheel Size: 27.5"

Intended Use: XC Trail

Lightning fast, the Thunderbolt is our vision of a perfect XC-trail bike. With short, playful chainstays and a wide range of adjustments, it’s at home on technical climbs, powering through the rough stuff, and popping off every trail feature you lay eyes on.

Grease ports in key pivot locations make for a stiffer, lighter, and lower-maintenance bike, and the Smoothwall carbon frame on Thunderbolt 790 MSL is a trim 2350g.

Frame Geometry
xs
sm
md
lg
xl
  • TTH. Top Tube Length - HORZ (mm)
  • 540
    565
    590
    615
    645
  • TTL. Top Tube length - Actual (mm)
  • N/A
    N/A
    N/A
    N/A
    N/A
  • HTA. Head Tube Angle (deg)
  • 66.5 - 68.2
    66.5 - 68.2
    66.5 - 68.2
    66.5 - 68.2
    66.5 - 68.2
  • HTL. Head Tube length (mm)
  • 100
    110
    120
    130
    145
  • STA. Seat Tube Angle - Effective (deg)
  • 73.0 - 74.7
    73.0 - 74.7
    73.0 - 74.7
    73.0 - 74.7
    73.0 - 74.7
  • STL. Seat Tube length (mm)
  • 381
    419
    457
    483
    521
  • CSL. Chainstay Length (mm)
  • 422
    422
    422
    422
    422
  • BBD. Bottom bracket drop (mm)
  • 20.2 - 0.5
    20.2 - 0.5
    20.2 - 0.5
    20.2 - 0.5
    20.2 - 0.5
  • BBH. Bottom bracket height (mm)
  • N/A
    N/A
    N/A
    N/A
    N/A
  • R. Reach (mm)
  • 368 - 385
    390 - 408
    413 - 430
    436 - 452
    461 - 479
  • S. Stack (mm)
  • 554 - 562
    563 - 571
    572 - 581
    582 - 590
    596 - 604
  • SH. Standover Height (mm)
  • 702
    702
    702
    702
    702
  • WB. Wheelbase (mm)
  • 1079
    1105
    1131
    1157
    1189
  • FC. Front-Centre (mm)
  • N/A
    N/A
    N/A
    N/A
    N/A
  • FO. Fork Offset ()
  • N/A
    N/A
    N/A
    N/A
    N/A

* Not all sizes available in all markets
