Slayer

Slayer

Quick Specs
  • Designed For All Mountain
  • F. Travel 180 (27.5") or 170 (29") MM
  • R. Travel 180 (27.5") or 170 (29") MM
  • Wheel Size 27.5" or 29"

The ultimate big mountain platform, the Slayer is meant for riding fast and sending it deep. Designed to be able to pedal to the top of any descent, this bike allows you to shred corners, hit gaps, and ride harder than you ever thought possible.

Whether you're smashing through the roughest trails imaginable or scrubbing lips in the park, the Slayer is built for those who charge. We’ve made it longer and slacker, with better small-bump sensitivity and a more progressive end-stroke. For those who like to fine-tune their ride before they shred, we kept the RIDE-4 adjustment system to allow for further geometry and ride feel customization. Rocky Mountain led the original freeride movement, and the Slayer continues the legacy.

Slayer Carbon 90 (29") 11
MSRP $3,099 USD
MSRP $3,099 USD
MSRP $3,299 USD
MSRP $3,299 USD
MSRP $3,999 USD
MSRP $3,999 USD
MSRP $4,999 USD
MSRP $5,999 USD
MSRP $5,999 USD
MSRP $7,999 USD
MSRP $7,999 USD
MSRP $3,099 USD
MSRP $3,099 USD
MSRP $7,999 USD
MSRP $7,999 USD
MSRP $5,999 USD
MSRP $5,999 USD
MSRP $4,999 USD
MSRP $3,999 USD
MSRP $3,999 USD
MSRP $3,299 USD
MSRP $3,299 USD
Colour Colour Colour
Colour Colour Colour
Colour Colour Colour
Colour Colour Colour
Colour Colour Colour
Colour Colour Colour
Colour Colour Colour
Colour Colour Colour
Colour Colour Colour
Colour Colour Colour
Colour Colour Colour

Specifications: Slayer Carbon 90 (29")

    • Frame SMOOTHWALL Carbon Front Triangle. FORM Alloy Rear Triangle. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. RIDE-4 Adjustable Geometry.
    • Sizes M - L - XL
    • Fork Fox 36 Float EVOL GRIP2 Factory 29: 170mm 44mm Offset / 27.5: 180mm 37mm Offset
    • Front Travel 170mm. (200mm Dual Crown Compatible)
    • Shock Fox DHX2 Factory, 2-Position Lockout, SLS Spring, MD = 400 lb / LG = 450 lb / XL = 500 lb
    • Rear Travel 170mm
    • Headset FSA Orbit NO.57E
    • Stem Rocky Mountain 35 CNC
    • Handlebar Race Face SixC 820mm
    • Grips Rocky Mountain Lock On XC
    • Brakes Shimano XTR Trail 4 Piston / Shimano RT86 203mm / Shimano RT86 203mm
    • Brake Levers Shimano XTR Trail 4 Piston
    • Shifters Shimano XTR
    • Rear Derailleur Shimano XTR
    • Cranks & Chainrings Race Face Next R Cinch 29: 32T / 27.5: 34T
    • Bottom Bracket Race Face BB92 30mm
    • Cassette Shimano XTR 12s 10-51T
    • Chain Shimano XTR 12s
    • Front Hub Rocky Mountain Sealed Boost 15mm
    • Rear Hub DT Swiss 350 Boost 148mm
    • Spokes DT Swiss Champion 2.0
    • Rims Race Face ARC 30
    • Tires Maxxis Minion DHF WT Double Down Maxx Grip 3C Tubeless Ready 2.5 / Maxxis Aggressor WT Double Down Tubeless Ready 2.5
    • Seatpost Race Face Turbine R (by Fox) Dropper 30.9mm
    • Saddle WTB Volt Race 142
    • Weight 14.95 KG / 33.0 LBS
    • Frame SMOOTHWALL Carbon Front Triangle. FORM Alloy Rear Triangle. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. RIDE-4 Adjustable Geometry.
    • Sizes S - M - L - XL
    • Fork Fox 36 Float EVOL GRIP2 Factory 29: 170mm 44mm Offset / 27.5: 180mm 37mm Offset
    • Front Travel 180mm. (200mm Dual Crown Compatible)
    • Shock Fox DHX2 Factory, 2-Position Lockout, SLS Spring, SM = 350 lb / MD = 400 lb / LG = 450 lb / XL = 500 lb
    • Rear Travel 180mm
    • Headset FSA Orbit NO.57E
    • Stem Rocky Mountain 35 CNC
    • Handlebar Race Face SixC 820mm
    • Grips Rocky Mountain Lock On XC
    • Brakes Shimano XTR Trail 4 Piston / Shimano RT86 203mm / Shimano RT86 203mm
    • Brake Levers Shimano XTR Trail 4 Piston
    • Shifters Shimano XTR
    • Rear Derailleur Shimano XTR
    • Cranks & Chainrings Race Face Next R Cinch 29: 32T / 27.5: 34T
    • Bottom Bracket Race Face BB92 30mm
    • Cassette Shimano XTR 12s 10-51T
    • Chain Shimano XTR 12s
    • Front Hub Rocky Mountain Sealed Boost 15mm
    • Rear Hub DT Swiss 350 Boost 148mm
    • Spokes DT Swiss Champion 2.0
    • Rims Race Face ARC 30
    • Tires Maxxis Minion DHF WT Double Down Maxx Grip 3C Tubeless Ready 2.5 / Maxxis Aggressor WT Double Down Tubeless Ready 2.5
    • Seatpost Race Face Turbine R (by Fox) Dropper 30.9mm
    • Saddle WTB Volt Race 142
    • Weight 15.21 KG / 33.5 LBS
    • Frame SMOOTHWALL Carbon Front Triangle. FORM Alloy Rear Triangle. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. RIDE-4 Adjustable Geometry.
    • Sizes M - L - XL
    • Fork RockShox Lyrik Ultimate RC2 29: 170mm 42mm Offset / 27.5: 180mm 37mm Offset
    • Front Travel 170mm. (200mm Dual Crown Compatible)
    • Shock RockShox Super Deluxe Coil Ultimate RCT, MD = 400 lb / LG = 450 lb / XL = 500 lb
    • Rear Travel 170mm
    • Headset FSA Orbit NO.57E
    • Stem Rocky Mountain 35 AM
    • Handlebar Race Face Atlas 820mm
    • Grips Rocky Mountain Lock On XC
    • Brakes Shimano XT Trail 4 Piston / Shimano RT66 203mm / Shimano RT66 203mm
    • Brake Levers Shimano XT Trail 4 Piston
    • Shifters Shimano XT
    • Rear Derailleur Shimano XT
    • Cranks & Chainrings Race Face Turbine Cinch 29: 32T / 27.5: 34T
    • Bottom Bracket Race Face BB92 30mm
    • Cassette Shimano XT 10-51T
    • Chain Shimano HG8100
    • Front Hub Rocky Mountain Sealed Boost 15mm Torque Cap
    • Rear Hub DT Swiss 370 Boost 148mm
    • Spokes DT Swiss Champion 2.0
    • Rims Race Face AR 30
    • Tires Maxxis Minion DHF WT Double Down Maxx Grip 3C Tubeless Ready 2.5 / Maxxis Aggressor WT Double Down Tubeless Ready 2.5
    • Seatpost OneUp Dropper Post 30.9mm
    • Saddle WTB Volt Race 142
    • Weight 15.5 KG / 34.2 LBS
    • Frame SMOOTHWALL Carbon Front Triangle. FORM Alloy Rear Triangle. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. RIDE-4 Adjustable Geometry.
    • Sizes S - M - L - XL
    • Fork RockShox Lyrik Ultimate RC2 29: 170mm 42mm Offset / 27.5: 180mm 37mm Offset
    • Front Travel 180mm. (200mm Dual Crown Compatible)
    • Shock RockShox Super Deluxe Coil Ultimate RCT, SM = 350 lb / MD = 400 lb / LG = 450 lb / XL = 500 lb
    • Rear Travel 180mm
    • Headset FSA Orbit NO.57E
    • Stem Rocky Mountain 35 AM
    • Handlebar Race Face Atlas 820mm
    • Grips Rocky Mountain Lock On XC
    • Brakes Shimano XT Trail 4 Piston / Shimano RT66 203mm / Shimano RT66 203mm
    • Brake Levers Shimano XT Trail 4 Piston
    • Shifters Shimano XT
    • Rear Derailleur Shimano XT
    • Cranks & Chainrings Race Face Turbine Cinch 29: 32T / 27.5: 34T
    • Bottom Bracket Race Face BB92 30mm
    • Cassette Shimano XT 10-51T
    • Chain Shimano HG8100
    • Front Hub Rocky Mountain Sealed Boost 15mm Torque Cap
    • Rear Hub DT Swiss 370 Boost 148mm
    • Spokes DT Swiss Champion 2.0
    • Rims Race Face AR 30
    • Tires Maxxis Minion DHF WT Double Down Maxx Grip 3C Tubeless Ready 2.5 / Maxxis Aggressor WT Double Down Tubeless Ready 2.5
    • Seatpost OneUp Dropper Post 30.9mm
    • Saddle WTB Volt Race 142
    • Weight 15.5 KG / 34.2 LBS
    • Frame SMOOTHWALL Carbon Front Triangle. FORM Alloy Rear Triangle. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. RIDE-4 Adjustable Geometry.
    • Sizes M - L - XL
    • Fork RockShox Lyrik Select RC 29: 170mm 42mm Offset / 27.5: 180mm 37mm Offset
    • Front Travel 170mm. (200mm Dual Crown Compatible)
    • Shock RockShox Super Deluxe Coil Ultimate RCT, MD = 400 lb / LG = 450 lb / XL = 500 lb
    • Rear Travel 170mm
    • Headset FSA Orbit NO.57E
    • Stem Rocky Mountain 35 AM
    • Handlebar Rocky Mountain AM 780mm
    • Grips Rocky Mountain Lock On XC
    • Brakes Shimano SLX Trail 4 Piston / Shimano RT66 203mm / Shimano RT66 203mm
    • Brake Levers Shimano SLX Trail 4 Piston
    • Shifters Shimano SLX
    • Rear Derailleur Shimano XT
    • Cranks & Chainrings Race Face Aeffect Cinch 32T Steel
    • Bottom Bracket Shimano SM-BBMT500
    • Cassette Shimano SLX 10-51T
    • Chain Shimano HG7100
    • Front Hub Rocky Mountain Sealed Boost 15mm Torque Cap
    • Rear Hub DT Swiss 370 Boost 148mm
    • Spokes DT Swiss Champion 2.0
    • Rims WTB ST i30 TCS 2.0 Tubeless
    • Tires Maxxis Minion DHF WT Double Down Maxx Grip 3C Tubeless Ready 29 x 2.5 / Maxxis Aggressor WT Double Down Tubeless Ready 29 x 2.5
    • Seatpost OneUp Dropper Post 30.9mm
    • Saddle WTB Volt Race 142
    • Weight 15.44 KG / 34 LBS
    • Frame FORM Alloy. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. 2-Bolt ISCG05 Tabs. RIDE-4 Adjustable Geometry.
    • Sizes M - L - XL
    • Fork RockShox Lyrik Select RC 29: 170mm 42mm Offset / 27.5: 180mm 37mm Offset
    • Front Travel 170mm. (200mm Dual Crown Compatible)
    • Shock RockShox Super Deluxe Coil Ultimate RCT, MD = 400 lb / LG = 450 lb / XL = 500 lb
    • Rear Travel 170mm
    • Headset FSA Orbit NO.57E
    • Stem Rocky Mountain 35 AM
    • Handlebar Rocky Mountain AM 780mm
    • Grips Rocky Mountain Lock On XC
    • Brakes Shimano SLX Trail 4 Piston / Shimano RT66 203mm / Shimano RT66 203mm
    • Brake Levers Shimano SLX Trail 4 Piston
    • Shifters Shimano SLX
    • Rear Derailleur Shimano XT
    • Cranks & Chainrings Race Face Aeffect Cinch 29: 32T / 27.5: 34T
    • Bottom Bracket Shimano SM-BBMT500
    • Cassette Shimano SLX 10-51T
    • Chain Shimano HG7100
    • Front Hub Rocky Mountain Sealed Boost 15mm Torque Cap
    • Rear Hub DT Swiss 370 Boost 148mm
    • Spokes DT Swiss Champion 2.0
    • Rims WTB ST i30 TCS 2.0 Tubeless
    • Tires Maxxis Minion DHF WT Double Down Maxx Grip 3C Tubeless Ready 2.5 / Maxxis Aggressor WT Double Down Tubeless Ready 2.5
    • Seatpost Race Face Aeffect R Dropper 30.9mm
    • Saddle WTB Volt Race 142
    • Weight 16.83 KG / 37.1 LBS
    • Frame FORM Alloy. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. 2-Bolt ISCG05 Tabs. RIDE-4 Adjustable Geometry.
    • Sizes S - M - L - XL
    • Fork RockShox Lyrik Select RC 29: 170mm 42mm Offset / 27.5: 180mm 37mm Offset
    • Front Travel 180mm. (200mm Dual Crown Compatible)
    • Shock RockShox Super Deluxe Coil Ultimate RCT, SM = 350 lb / MD = 400 lb / LG = 450 lb / XL = 500 lb
    • Rear Travel 180mm
    • Headset FSA Orbit NO.57E
    • Stem Rocky Mountain 35 AM
    • Handlebar Rocky Mountain AM 780mm
    • Grips Rocky Mountain Lock On XC
    • Brakes Shimano SLX Trail 4 Piston / Shimano RT66 203mm / Shimano RT66 203mm
    • Brake Levers Shimano SLX Trail 4 Piston
    • Shifters Shimano SLX
    • Rear Derailleur Shimano XT
    • Cranks & Chainrings Race Face Aeffect Cinch 29: 32T / 27.5: 34T
    • Bottom Bracket Shimano SM-BBMT500
    • Cassette Shimano SLX 10-51T
    • Chain Shimano HG7100
    • Front Hub Rocky Mountain Sealed Boost 15mm Torque Cap
    • Rear Hub DT Swiss 370 Boost 148mm
    • Spokes DT Swiss Champion 2.0
    • Rims WTB ST i30 TCS 2.0 Tubeless
    • Tires Maxxis Minion DHF WT Double Down Maxx Grip 3C Tubeless Ready 27.5 x 2.5 / Maxxis Aggressor WT Double Down Tubeless Ready 27.5 x 2.5
    • Seatpost Race Face Aeffect R Dropper 30.9mm
    • Saddle WTB Volt Race 142
    • Weight 16.37 KG / 36.1 LBS
    • Frame FORM Alloy. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. 2-Bolt ISCG05 Tabs. RIDE-4 Adjustable Geometry.
    • Sizes M - L - XL
    • Fork RockShox Yari RC 29: 170mm 42mm Offset / 27.5: 180mm 37mm Offset
    • Front Travel 170mm. (200mm Dual Crown Compatible)
    • Shock RockShox Super Deluxe Coil Select, MD = 400 lb / LG = 450 lb / XL = 500 lb,
    • Rear Travel 170mm
    • Headset FSA Orbit NO.57E
    • Stem Rocky Mountain 35 AM
    • Handlebar Rocky Mountain AM 780mm
    • Grips Rocky Mountain Lock On XC
    • Brakes Shimano MT520 4 Piston / Shimano RT64 203mm / Shimano RT64 203mm
    • Brake Levers Shimano MT520 4 Piston
    • Shifters Sram SX Eagle
    • Rear Derailleur Sram SX Eagle
    • Cranks & Chainrings Sram SX Eagle 29: 32T / 27.5: 34T
    • Bottom Bracket Sram BB92 DUB
    • Cassette Sram PG-1210 11-50T
    • Chain Sram SX Eagle
    • Front Hub Shimano MT400 Boost 15mm
    • Rear Hub Shimano MT400 Boost 148mm
    • Spokes 2.0 Stainless
    • Rims WTB ST i30 TCS 2.0 Tubeless
    • Tires Maxxis Minion DHF WT Double Down Maxx Grip 3C Tubeless Ready 2.5 / Maxxis Aggressor WT Double Down Tubeless Ready 2.5
    • Seatpost Rocky Mountain Toonie Drop 30.9mm
    • Saddle WTB Volt Race 142
    • Weight 17.25 KG / 38 LBS
    • Frame FORM Alloy. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. 2-Bolt ISCG05 Tabs. RIDE-4 Adjustable Geometry.
    • Sizes S - M - L - XL
    • Fork RockShox Yari Motion Control RC 180mm 37mm Offset
    • Front Travel 180mm. (200mm Dual Crown Compatible)
    • Shock RockShox Super Deluxe Coil Select, SM = 350 lb / MD = 400 lb / LG = 450 lb / XL = 500 lb
    • Rear Travel 180mm
    • Headset FSA Orbit NO.57E
    • Stem Rocky Mountain 35 AM
    • Handlebar Rocky Mountain AM 780mm
    • Grips Rocky Mountain Lock On XC
    • Brakes Shimano MT520 4 Piston / Shimano RT64 203mm / Shimano RT64 203mm
    • Brake Levers Shimano MT520 4 Piston
    • Shifters Sram SX Eagle
    • Rear Derailleur Sram SX Eagle
    • Cranks & Chainrings Sram SX Eagle 34T
    • Bottom Bracket Sram BB92 DUB
    • Cassette Sram PG-1210 11-50T
    • Chain Sram SX Eagle
    • Front Hub Shimano MT400 Boost 15mm
    • Rear Hub Shimano MT400 Boost 148mm
    • Spokes 2.0 Stainless
    • Rims WTB ST i30 TCS 2.0 Tubeless
    • Tires Maxxis Minion DHF WT Double Down Maxx Grip 3C Tubeless Ready 27.5 x 2.5 / Maxxis Aggressor WT Double Down Tubeless Ready 27.5 x 2.5
    • Seatpost Rocky Mountain Toonie Drop 30.9mm
    • Saddle WTB Volt Race 142
    • Weight 16.9 KG / 37.3 LBS
    • Frame SMOOTHWALL Carbon Front Triangle. FORM Alloy Rear Triangle. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. RIDE-4 Adjustable Geometry.
    • Sizes M - L - XL
    • Front Travel 170mm. (200mm Dual Crown Compatible)
    • Shock Fox DHX2 Factory, 2-Position Lockout, SLS Spring, MD = 400 lb / LG = 450 lb / XL = 500 lb
    • Rear Travel 170mm
    • Brakes 0 / 0 / 0
    • Tires 0 / 0
    • Weight 4.2 KG / 9.26 LBS
    • Frame SMOOTHWALL Carbon Front Triangle. FORM Alloy Rear Triangle. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. RIDE-4 Adjustable Geometry.
    • Sizes S - M - L - XL
    • Front Travel 180mm. (200mm Dual Crown Compatible)
    • Shock Fox DHX2 Factory, 2-Position Lockout, SLS Spring, SM = 350 lb / MD = 400 lb / LG = 450 lb / XL = 500 lb
    • Rear Travel 180mm
    • Brakes 0 / 0 / 0
    • Tires 0 / 0
    • Weight 4 KG / 8.82 LBS

We make every effort to ensure accuracy, but reserve the right to update specifications & prices without notification

Geometry: Slayer Carbon 90 (29")

Riding Style

m l xl
TTH Top Tube Length - HORZ 600 600mm 628 628mm 657 657mm
HTA Head Tube Angle 63.8 63.8deg 63.8 63.8deg 63.8 63.8deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.8 75.8deg 75.8 75.8deg 75.8 75.8deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 443 443mm 443 443mm 443 443mm
BBD Bottom bracket drop 34 34mm 34 34mm 34 34mm
R Reach 442 442mm 469 469mm 492 492mm
S Stack 622 622mm 635 635mm 649 649mm
SH Standover Height 830 830mm 830 830mm 830 830mm
WB Wheelbase 1,220 1,220mm 1,249 1,249mm 1,286 1,286mm
m l xl
TTH Top Tube Length - HORZ 599 599mm 627 627mm 656 656mm
HTA Head Tube Angle 64.1 64.1deg 64.1 64.1deg 64.1 64.1deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.1 76.1deg 76.1 76.1deg 76.1 76.1deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 442 442mm 442 442mm 442 442mm
BBD Bottom bracket drop 30 30mm 30 30mm 30 30mm
R Reach 446 446mm 471 471mm 496 496mm
S Stack 619 619mm 632 632mm 646 646mm
SH Standover Height 831 831mm 831 831mm 831 831mm
WB Wheelbase 1,219 1,219mm 1,248 1,248mm 1,285 1,285mm
m l xl
TTH Top Tube Length - HORZ 598 598mm 626 626mm 655 655mm
HTA Head Tube Angle 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.5 76.5deg 76.5 76.5deg 76.5 76.5deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 442 442mm 442 442mm 442 442mm
BBD Bottom bracket drop 25 25mm 25 25mm 25 25mm
R Reach 450 450mm 475 475mm 500 500mm
S Stack 616 616mm 629 629mm 643 643mm
SH Standover Height 832 832mm 832 832mm 832 832mm
WB Wheelbase 1,218 1,218mm 1,247 1,247mm 1,284 1,284mm
m l xl
TTH Top Tube Length - HORZ 595 595mm 623 623mm 652 652mm
HTA Head Tube Angle 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.8 76.8deg 76.8 76.8deg 76.8 76.8deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 441 441mm 441 441mm 441 441mm
BBD Bottom bracket drop 18 18mm 18 18mm 18 18mm
R Reach 453 453mm 478 478mm 503 503mm
S Stack 614 614mm 627 627mm 641 641mm
SH Standover Height 833 833mm 833 833mm 833 833mm
WB Wheelbase 1,215 1,215mm 1,244 1,244mm 1,281 1,281mm
m l xl
TTH Top Tube Length - HORZ 600 600mm 628 628mm 657 657mm
HTA Head Tube Angle 63.8 63.8deg 63.8 63.8deg 63.8 63.8deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.8 75.8deg 75.8 75.8deg 75.8 75.8deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 443 443mm 443 443mm 443 443mm
BBD Bottom bracket drop 34 34mm 34 34mm 34 34mm
R Reach 442 442mm 469 469mm 492 492mm
S Stack 622 622mm 635 635mm 649 649mm
SH Standover Height 830 830mm 830 830mm 830 830mm
WB Wheelbase 1,220 1,220mm 1,249 1,249mm 1,286 1,286mm
m l xl
TTH Top Tube Length - HORZ 599 599mm 627 627mm 656 656mm
HTA Head Tube Angle 64.1 64.1deg 64.1 64.1deg 64.1 64.1deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.1 76.1deg 76.1 76.1deg 76.1 76.1deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 442 442mm 442 442mm 442 442mm
BBD Bottom bracket drop 30 30mm 30 30mm 30 30mm
R Reach 446 446mm 471 471mm 496 496mm
S Stack 619 619mm 632 632mm 646 646mm
SH Standover Height 831 831mm 831 831mm 831 831mm
WB Wheelbase 1,219 1,219mm 1,248 1,248mm 1,285 1,285mm
m l xl
TTH Top Tube Length - HORZ 598 598mm 626 626mm 655 655mm
HTA Head Tube Angle 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.5 76.5deg 76.5 76.5deg 76.5 76.5deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 442 442mm 442 442mm 442 442mm
BBD Bottom bracket drop 25 25mm 25 25mm 25 25mm
R Reach 450 450mm 475 475mm 500 500mm
S Stack 616 616mm 629 629mm 643 643mm
SH Standover Height 832 832mm 832 832mm 832 832mm
WB Wheelbase 1,218 1,218mm 1,247 1,247mm 1,284 1,284mm
m l xl
TTH Top Tube Length - HORZ 595 595mm 623 623mm 652 652mm
HTA Head Tube Angle 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.8 76.8deg 76.8 76.8deg 76.8 76.8deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 441 441mm 441 441mm 441 441mm
BBD Bottom bracket drop 18 18mm 18 18mm 18 18mm
R Reach 453 453mm 478 478mm 503 503mm
S Stack 614 614mm 627 627mm 641 641mm
SH Standover Height 833 833mm 833 833mm 833 833mm
WB Wheelbase 1,215 1,215mm 1,244 1,244mm 1,281 1,281mm
m l xl
TTH Top Tube Length - HORZ 600 600mm 628 628mm 657 657mm
HTA Head Tube Angle 63.8 63.8deg 63.8 63.8deg 63.8 63.8deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.8 75.8deg 75.8 75.8deg 75.8 75.8deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 443 443mm 443 443mm 443 443mm
BBD Bottom bracket drop 34 34mm 34 34mm 34 34mm
R Reach 442 442mm 469 469mm 492 492mm
S Stack 622 622mm 635 635mm 649 649mm
SH Standover Height 830 830mm 830 830mm 830 830mm
WB Wheelbase 1,220 1,220mm 1,249 1,249mm 1,286 1,286mm
m l xl
TTH Top Tube Length - HORZ 599 599mm 627 627mm 656 656mm
HTA Head Tube Angle 64.1 64.1deg 64.1 64.1deg 64.1 64.1deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.1 76.1deg 76.1 76.1deg 76.1 76.1deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 442 442mm 442 442mm 442 442mm
BBD Bottom bracket drop 30 30mm 30 30mm 30 30mm
R Reach 446 446mm 471 471mm 496 496mm
S Stack 619 619mm 632 632mm 646 646mm
SH Standover Height 831 831mm 831 831mm 831 831mm
WB Wheelbase 1,219 1,219mm 1,248 1,248mm 1,285 1,285mm
m l xl
TTH Top Tube Length - HORZ 598 598mm 626 626mm 655 655mm
HTA Head Tube Angle 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.5 76.5deg 76.5 76.5deg 76.5 76.5deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 442 442mm 442 442mm 442 442mm
BBD Bottom bracket drop 25 25mm 25 25mm 25 25mm
R Reach 450 450mm 475 475mm 500 500mm
S Stack 616 616mm 629 629mm 643 643mm
SH Standover Height 832 832mm 832 832mm 832 832mm
WB Wheelbase 1,218 1,218mm 1,247 1,247mm 1,284 1,284mm
m l xl
TTH Top Tube Length - HORZ 595 595mm 623 623mm 652 652mm
HTA Head Tube Angle 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.8 76.8deg 76.8 76.8deg 76.8 76.8deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 441 441mm 441 441mm 441 441mm
BBD Bottom bracket drop 18 18mm 18 18mm 18 18mm
R Reach 453 453mm 478 478mm 503 503mm
S Stack 614 614mm 627 627mm 641 641mm
SH Standover Height 833 833mm 833 833mm 833 833mm
WB Wheelbase 1,215 1,215mm 1,244 1,244mm 1,281 1,281mm
m l xl
TTH Top Tube Length - HORZ 600 600mm 628 628mm 657 657mm
HTA Head Tube Angle 63.8 63.8deg 63.8 63.8deg 63.8 63.8deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.8 75.8deg 75.8 75.8deg 75.8 75.8deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 443 443mm 443 443mm 443 443mm
BBD Bottom bracket drop 34 34mm 34 34mm 34 34mm
R Reach 442 442mm 469 469mm 492 492mm
S Stack 622 622mm 635 635mm 649 649mm
SH Standover Height 830 830mm 830 830mm 830 830mm
WB Wheelbase 1,220 1,220mm 1,249 1,249mm 1,286 1,286mm
m l xl
TTH Top Tube Length - HORZ 599 599mm 627 627mm 656 656mm
HTA Head Tube Angle 64.1 64.1deg 64.1 64.1deg 64.1 64.1deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.1 76.1deg 76.1 76.1deg 76.1 76.1deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 442 442mm 442 442mm 442 442mm
BBD Bottom bracket drop 30 30mm 30 30mm 30 30mm
R Reach 446 446mm 471 471mm 496 496mm
S Stack 619 619mm 632 632mm 646 646mm
SH Standover Height 831 831mm 831 831mm 831 831mm
WB Wheelbase 1,219 1,219mm 1,248 1,248mm 1,285 1,285mm
m l xl
TTH Top Tube Length - HORZ 598 598mm 626 626mm 655 655mm
HTA Head Tube Angle 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.5 76.5deg 76.5 76.5deg 76.5 76.5deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 442 442mm 442 442mm 442 442mm
BBD Bottom bracket drop 25 25mm 25 25mm 25 25mm
R Reach 450 450mm 475 475mm 500 500mm
S Stack 616 616mm 629 629mm 643 643mm
SH Standover Height 832 832mm 832 832mm 832 832mm
WB Wheelbase 1,218 1,218mm 1,247 1,247mm 1,284 1,284mm
m l xl
TTH Top Tube Length - HORZ 595 595mm 623 623mm 652 652mm
HTA Head Tube Angle 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.8 76.8deg 76.8 76.8deg 76.8 76.8deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 441 441mm 441 441mm 441 441mm
BBD Bottom bracket drop 18 18mm 18 18mm 18 18mm
R Reach 453 453mm 478 478mm 503 503mm
S Stack 614 614mm 627 627mm 641 641mm
SH Standover Height 833 833mm 833 833mm 833 833mm
WB Wheelbase 1,215 1,215mm 1,244 1,244mm 1,281 1,281mm
m l xl
TTH Top Tube Length - HORZ 600 600mm 628 628mm 657 657mm
HTA Head Tube Angle 63.8 63.8deg 63.8 63.8deg 63.8 63.8deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.8 75.8deg 75.8 75.8deg 75.8 75.8deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 443 443mm 443 443mm 443 443mm
BBD Bottom bracket drop 34 34mm 34 34mm 34 34mm
R Reach 442 442mm 469 469mm 492 492mm
S Stack 622 622mm 635 635mm 649 649mm
SH Standover Height 830 830mm 830 830mm 830 830mm
WB Wheelbase 1,220 1,220mm 1,249 1,249mm 1,286 1,286mm
m l xl
TTH Top Tube Length - HORZ 599 599mm 627 627mm 656 656mm
HTA Head Tube Angle 64.1 64.1deg 64.1 64.1deg 64.1 64.1deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.1 76.1deg 76.1 76.1deg 76.1 76.1deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 442 442mm 442 442mm 442 442mm
BBD Bottom bracket drop 30 30mm 30 30mm 30 30mm
R Reach 446 446mm 471 471mm 496 496mm
S Stack 619 619mm 632 632mm 646 646mm
SH Standover Height 831 831mm 831 831mm 831 831mm
WB Wheelbase 1,219 1,219mm 1,248 1,248mm 1,285 1,285mm
m l xl
TTH Top Tube Length - HORZ 598 598mm 626 626mm 655 655mm
HTA Head Tube Angle 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.5 76.5deg 76.5 76.5deg 76.5 76.5deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 442 442mm 442 442mm 442 442mm
BBD Bottom bracket drop 25 25mm 25 25mm 25 25mm
R Reach 450 450mm 475 475mm 500 500mm
S Stack 616 616mm 629 629mm 643 643mm
SH Standover Height 832 832mm 832 832mm 832 832mm
WB Wheelbase 1,218 1,218mm 1,247 1,247mm 1,284 1,284mm
m l xl
TTH Top Tube Length - HORZ 595 595mm 623 623mm 652 652mm
HTA Head Tube Angle 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.8 76.8deg 76.8 76.8deg 76.8 76.8deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 441 441mm 441 441mm 441 441mm
BBD Bottom bracket drop 18 18mm 18 18mm 18 18mm
R Reach 453 453mm 478 478mm 503 503mm
S Stack 614 614mm 627 627mm 641 641mm
SH Standover Height 833 833mm 833 833mm 833 833mm
WB Wheelbase 1,215 1,215mm 1,244 1,244mm 1,281 1,281mm
m l xl
TTH Top Tube Length - HORZ 600 600mm 628 628mm 657 657mm
HTA Head Tube Angle 63.8 63.8deg 63.8 63.8deg 63.8 63.8deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.8 75.8deg 75.8 75.8deg 75.8 75.8deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 443 443mm 443 443mm 443 443mm
BBD Bottom bracket drop 34 34mm 34 34mm 34 34mm
R Reach 442 442mm 469 469mm 492 492mm
S Stack 622 622mm 635 635mm 649 649mm
SH Standover Height 830 830mm 830 830mm 830 830mm
WB Wheelbase 1,220 1,220mm 1,249 1,249mm 1,286 1,286mm
m l xl
TTH Top Tube Length - HORZ 599 599mm 627 627mm 656 656mm
HTA Head Tube Angle 64.1 64.1deg 64.1 64.1deg 64.1 64.1deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.1 76.1deg 76.1 76.1deg 76.1 76.1deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 442 442mm 442 442mm 442 442mm
BBD Bottom bracket drop 30 30mm 30 30mm 30 30mm
R Reach 446 446mm 471 471mm 496 496mm
S Stack 619 619mm 632 632mm 646 646mm
SH Standover Height 831 831mm 831 831mm 831 831mm
WB Wheelbase 1,219 1,219mm 1,248 1,248mm 1,285 1,285mm
m l xl
TTH Top Tube Length - HORZ 598 598mm 626 626mm 655 655mm
HTA Head Tube Angle 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.5 76.5deg 76.5 76.5deg 76.5 76.5deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 442 442mm 442 442mm 442 442mm
BBD Bottom bracket drop 25 25mm 25 25mm 25 25mm
R Reach 450 450mm 475 475mm 500 500mm
S Stack 616 616mm 629 629mm 643 643mm
SH Standover Height 832 832mm 832 832mm 832 832mm
WB Wheelbase 1,218 1,218mm 1,247 1,247mm 1,284 1,284mm
m l xl
TTH Top Tube Length - HORZ 595 595mm 623 623mm 652 652mm
HTA Head Tube Angle 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg
HTL Head Tube length 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.8 76.8deg 76.8 76.8deg 76.8 76.8deg
STL Seat Tube length 420 420mm 445 445mm 480 480mm
RC Rear Centre 441 441mm 441 441mm 441 441mm
BBD Bottom bracket drop 18 18mm 18 18mm 18 18mm
R Reach 453 453mm 478 478mm 503 503mm
S Stack 614 614mm 627 627mm 641 641mm
SH Standover Height 833 833mm 833 833mm 833 833mm
WB Wheelbase 1,215 1,215mm 1,244 1,244mm 1,281 1,281mm
s m l xl
TTH Top Tube Length - HORZ 574 574mm 598 598mm 624 624mm 660 660mm
HTA Head Tube Angle 63.9 63.9deg 63.9 63.9deg 63.9 63.9deg 63.9 63.9deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.4 75.4deg 75.4 75.4deg 75.4 75.4deg 75.4 75.4deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 431 431mm 431 431mm 431 431mm 431 431mm
BBD Bottom bracket drop 18 18mm 18 18mm 18 18mm 18 18mm
R Reach 419 419mm 444 444mm 469 469mm 494 494mm
S Stack 595 595mm 600 600mm 614 614mm 627 627mm
SH Standover Height 806 806mm 806 806mm 806 806mm 806 806mm
WB Wheelbase 1,180 1,180mm 1,205 1,205mm 1,234 1,234mm 1,273 1,273mm
s m l xl
TTH Top Tube Length - HORZ 573 573mm 597 597mm 623 623mm 659 659mm
HTA Head Tube Angle 64.2 64.2deg 64.2 64.2deg 64.2 64.2deg 64.2 64.2deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.7 75.7deg 75.7 75.7deg 75.7 75.7deg 75.7 75.7deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 430 430mm 430 430mm 430 430mm 430 430mm
BBD Bottom bracket drop 14 14mm 14 14mm 14 14mm 14 14mm
R Reach 422 422mm 447 447mm 472 472mm 497 497mm
S Stack 593 593mm 598 598mm 612 612mm 625 625mm
SH Standover Height 807 807mm 807 807mm 807 807mm 807 807mm
WB Wheelbase 1,179 1,179mm 1,204 1,204mm 1,233 1,233mm 1,272 1,272mm
s m l xl
TTH Top Tube Length - HORZ 573 573mm 597 597mm 622 622mm 658 658mm
HTA Head Tube Angle 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76 76deg 76 76deg 76 76deg 76 76deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 430 430mm 430 430mm 430 430mm 430 430mm
BBD Bottom bracket drop 10 10mm 10 10mm 10 10mm 10 10mm
R Reach 425 425mm 450 450mm 475 475mm 500 500mm
S Stack 591 591mm 596 596mm 610 610mm 623 623mm
SH Standover Height 809 809mm 809 809mm 809 809mm 809 809mm
WB Wheelbase 1,178 1,178mm 1,203 1,203mm 1,232 1,232mm 1,271 1,271mm
s m l xl
TTH Top Tube Length - HORZ 572 572mm 596 596mm 621 621mm 658 658mm
HTA Head Tube Angle 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.3 76.3deg 76.3 76.3deg 76.3 76.3deg 76.3 76.3deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 429 429mm 429 429mm 429 429mm 429 429mm
BBD Bottom bracket drop 6 6mm 6 6mm 6 6mm 6 6mm
R Reach 428 428mm 453 453mm 478 478mm 503 503mm
S Stack 589 589mm 594 594mm 608 608mm 621 621mm
SH Standover Height 811 811mm 811 811mm 811 811mm 811 811mm
WB Wheelbase 1,177 1,177mm 1,202 1,202mm 1,231 1,231mm 1,270 1,270mm
s m l xl
TTH Top Tube Length - HORZ 574 574mm 598 598mm 624 624mm 660 660mm
HTA Head Tube Angle 63.9 63.9deg 63.9 63.9deg 63.9 63.9deg 63.9 63.9deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.4 75.4deg 75.4 75.4deg 75.4 75.4deg 75.4 75.4deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 431 431mm 431 431mm 431 431mm 431 431mm
BBD Bottom bracket drop 18 18mm 18 18mm 18 18mm 18 18mm
R Reach 419 419mm 444 444mm 469 469mm 494 494mm
S Stack 595 595mm 600 600mm 614 614mm 627 627mm
SH Standover Height 806 806mm 806 806mm 806 806mm 806 806mm
WB Wheelbase 1,180 1,180mm 1,205 1,205mm 1,234 1,234mm 1,273 1,273mm
s m l xl
TTH Top Tube Length - HORZ 573 573mm 597 597mm 623 623mm 659 659mm
HTA Head Tube Angle 64.2 64.2deg 64.2 64.2deg 64.2 64.2deg 64.2 64.2deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.7 75.7deg 75.7 75.7deg 75.7 75.7deg 75.7 75.7deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 430 430mm 430 430mm 430 430mm 430 430mm
BBD Bottom bracket drop 14 14mm 14 14mm 14 14mm 14 14mm
R Reach 422 422mm 447 447mm 472 472mm 497 497mm
S Stack 593 593mm 598 598mm 612 612mm 625 625mm
SH Standover Height 807 807mm 807 807mm 807 807mm 807 807mm
WB Wheelbase 1,179 1,179mm 1,204 1,204mm 1,233 1,233mm 1,272 1,272mm
s m l xl
TTH Top Tube Length - HORZ 573 573mm 597 597mm 622 622mm 658 658mm
HTA Head Tube Angle 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76 76deg 76 76deg 76 76deg 76 76deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 430 430mm 430 430mm 430 430mm 430 430mm
BBD Bottom bracket drop 10 10mm 10 10mm 10 10mm 10 10mm
R Reach 425 425mm 450 450mm 475 475mm 500 500mm
S Stack 591 591mm 596 596mm 610 610mm 623 623mm
SH Standover Height 809 809mm 809 809mm 809 809mm 809 809mm
WB Wheelbase 1,178 1,178mm 1,203 1,203mm 1,232 1,232mm 1,271 1,271mm
s m l xl
TTH Top Tube Length - HORZ 572 572mm 596 596mm 621 621mm 658 658mm
HTA Head Tube Angle 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.3 76.3deg 76.3 76.3deg 76.3 76.3deg 76.3 76.3deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 429 429mm 429 429mm 429 429mm 429 429mm
BBD Bottom bracket drop 6 6mm 6 6mm 6 6mm 6 6mm
R Reach 428 428mm 453 453mm 478 478mm 503 503mm
S Stack 589 589mm 594 594mm 608 608mm 621 621mm
SH Standover Height 811 811mm 811 811mm 811 811mm 811 811mm
WB Wheelbase 1,177 1,177mm 1,202 1,202mm 1,231 1,231mm 1,270 1,270mm
s m l xl
TTH Top Tube Length - HORZ 574 574mm 598 598mm 624 624mm 660 660mm
HTA Head Tube Angle 63.9 63.9deg 63.9 63.9deg 63.9 63.9deg 63.9 63.9deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.4 75.4deg 75.4 75.4deg 75.4 75.4deg 75.4 75.4deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 431 431mm 431 431mm 431 431mm 431 431mm
BBD Bottom bracket drop 18 18mm 18 18mm 18 18mm 18 18mm
R Reach 419 419mm 444 444mm 469 469mm 494 494mm
S Stack 595 595mm 600 600mm 614 614mm 627 627mm
SH Standover Height 806 806mm 806 806mm 806 806mm 806 806mm
WB Wheelbase 1,180 1,180mm 1,205 1,205mm 1,234 1,234mm 1,273 1,273mm
s m l xl
TTH Top Tube Length - HORZ 573 573mm 597 597mm 623 623mm 659 659mm
HTA Head Tube Angle 64.2 64.2deg 64.2 64.2deg 64.2 64.2deg 64.2 64.2deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.7 75.7deg 75.7 75.7deg 75.7 75.7deg 75.7 75.7deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 430 430mm 430 430mm 430 430mm 430 430mm
BBD Bottom bracket drop 14 14mm 14 14mm 14 14mm 14 14mm
R Reach 422 422mm 447 447mm 472 472mm 497 497mm
S Stack 593 593mm 598 598mm 612 612mm 625 625mm
SH Standover Height 807 807mm 807 807mm 807 807mm 807 807mm
WB Wheelbase 1,179 1,179mm 1,204 1,204mm 1,233 1,233mm 1,272 1,272mm
s m l xl
TTH Top Tube Length - HORZ 573 573mm 597 597mm 622 622mm 658 658mm
HTA Head Tube Angle 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76 76deg 76 76deg 76 76deg 76 76deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 430 430mm 430 430mm 430 430mm 430 430mm
BBD Bottom bracket drop 10 10mm 10 10mm 10 10mm 10 10mm
R Reach 425 425mm 450 450mm 475 475mm 500 500mm
S Stack 591 591mm 596 596mm 610 610mm 623 623mm
SH Standover Height 809 809mm 809 809mm 809 809mm 809 809mm
WB Wheelbase 1,178 1,178mm 1,203 1,203mm 1,232 1,232mm 1,271 1,271mm
s m l xl
TTH Top Tube Length - HORZ 572 572mm 596 596mm 621 621mm 658 658mm
HTA Head Tube Angle 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg 64.8 64.8deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76.3 76.3deg 76.3 76.3deg 76.3 76.3deg 76.3 76.3deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 429 429mm 429 429mm 429 429mm 429 429mm
BBD Bottom bracket drop 6 6mm 6 6mm 6 6mm 6 6mm
R Reach 428 428mm 453 453mm 478 478mm 503 503mm
S Stack 589 589mm 594 594mm 608 608mm 621 621mm
SH Standover Height 811 811mm 811 811mm 811 811mm 811 811mm
WB Wheelbase 1,177 1,177mm 1,202 1,202mm 1,231 1,231mm 1,270 1,270mm
s m l xl
TTH Top Tube Length - HORZ 574 574mm 598 598mm 624 624mm 660 660mm
HTA Head Tube Angle 63.9 63.9deg 63.9 63.9deg 63.9 63.9deg 63.9 63.9deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.4 75.4deg 75.4 75.4deg 75.4 75.4deg 75.4 75.4deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 431 431mm 431 431mm 431 431mm 431 431mm
BBD Bottom bracket drop 18 18mm 18 18mm 18 18mm 18 18mm
R Reach 419 419mm 444 444mm 469 469mm 494 494mm
S Stack 595 595mm 600 600mm 614 614mm 627 627mm
SH Standover Height 806 806mm 806 806mm 806 806mm 806 806mm
WB Wheelbase 1,180 1,180mm 1,205 1,205mm 1,234 1,234mm 1,273 1,273mm
s m l xl
TTH Top Tube Length - HORZ 573 573mm 597 597mm 623 623mm 659 659mm
HTA Head Tube Angle 64.2 64.2deg 64.2 64.2deg 64.2 64.2deg 64.2 64.2deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 75.7 75.7deg 75.7 75.7deg 75.7 75.7deg 75.7 75.7deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 430 430mm 430 430mm 430 430mm 430 430mm
BBD Bottom bracket drop 14 14mm 14 14mm 14 14mm 14 14mm
R Reach 422 422mm 447 447mm 472 472mm 497 497mm
S Stack 593 593mm 598 598mm 612 612mm 625 625mm
SH Standover Height 807 807mm 807 807mm 807 807mm 807 807mm
WB Wheelbase 1,179 1,179mm 1,204 1,204mm 1,233 1,233mm 1,272 1,272mm
s m l xl
TTH Top Tube Length - HORZ 573 573mm 597 597mm 622 622mm 658 658mm
HTA Head Tube Angle 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg 64.5 64.5deg
HTL Head Tube length 90 90mm 95 95mm 110 110mm 125 125mm
STA Seat Tube Angle - Effective 76 76deg 76 76deg 76 76deg 76 76deg
STL Seat Tube length 380 380mm 420 420mm 460 460mm 480 480mm
RC Rear Centre 430 430mm 430 430mm 430 430mm 430 430mm
BBD Bottom bracket drop 10 10mm 10 10mm 10 10mm 10 10mm
R Reach 425 425mm 450 450mm 475 475mm 500 500mm
S Stack 591 591mm 596 596mm 610 610mm 623 623mm
SH Standover Height 809 809mm 809 809mm 809 809mm 809 809mm
WB Wheelbase 1,178 1,178mm 1,203 1,203mm 1,232 1,232mm 1,271 1,271mm
s m l xl
TTH Top Tube Length - HORZ
